143-9283 WINDOW GP-FRONTS/N 5SW1-UP

Group No: 143-9283
Part NumberPart NameQty
14466541 WINDOW GP-FRONT1
6C90332 SUPPORT1
6C90343 SUPPORT1
6C90354 ROLLER2
11223335 BALL BEARING2
6C90376 CATCH2
6C90387 WASHER (12.2X25X1-MM THK)2
13701838 ROD-CONNECTING1
13701849 ROD-CONNECTING1
112209110 WASHER4
112209211 RING2
112209312 BOLT-SOCKET HEAD (M8X1.25X40-MM)2
6C904313 SPRING2
6C904414 AXLE2
6C908115 LOCKWASHER3
6C922016 CLIP2
6C904717 WASHER (12X25X1.5-MM THK)4
6C914418 WASHER2
6C904819 NUT (M8X1-THD)4
112233420 CAP2
5C726121 NUT (M8X1.25-THD)2
6J647822 WASHER (0.28X0.63X0.13-IN THK)18
5C788323 BOLT-SOCKET HEAD (M6X1X16-MM)8
6C911924 SCREW (M5X0.8X12-MM)3
112209525 SCREW-HEX SOCKET (M6X1X16.7-MM)2
112210726 SPACER2
112209727 SCREW-HEX SOCKET2
112210528 RING2
3T084929 BOLT-SOCKET HEAD (M6X1X25-MM)4
137550630 WASHER-SPRING2
112209931 SEAL2
141451332 SPACER2
8T026933 BOLT-SOCKET HEAD (M6X1X20-MM)6
