143-9282 WIPER & MONITOR GP-WINDOW -UPPERS/N 5SW1-UP

Group No: 143-9282
Part NumberPart NameQty
12492711 SUPPORT AS1
8T42002 BOLT (M8X1.25X16-MM)2
6C90873 WASHER2
6C34314 ANTENNA4
13103275 CONVERTER AS (24-VOLT)1
12798386 CONTROL GP-WASHER & WIPER1
13103997 MOTOR AS-WINDOW WIPER (UPPER)1
6C91298 BOLT (M6X1X40-MM)1
6C87329 LINK AS1
6C922110 NUT (M24X1.5-THD)1
6C909711 NUT (M16X1-THD)1
6C910312 BOSS1
6C910413 CAP-WIPER1
5C955314 BOLT (M6X1X16-MM)11
6C913015 WASHER (6X18X1-MM THK)4
6C914216 BLADE AS-WIPER1
5C726117 NUT (M8X1.25-THD)2
5P411518 WASHER-HARD (7.2X19X2-MM THK)2
137531019 SUPPORT-WIPER1
6C907720 WASHER1
6C909221 WASHER2
6C912522 ASHTRAY AS1
137531123 SUPPORT-WIPER1
9X825624 WASHER (6.6X12X2-MM THK)11
6C908925 NUT-CAP4
9W033526 LIGHTER AS-CIGAR (24-VOLT)1
144019528 HOSE (460CM)
6C919929 CAP1
5C287430 NUT (M5X0.8-THD)2
121479531 PLUG2
5C289032 NUT (M6X1-THD)3
6C911833 BRACKET1
6C911934 SCREW (M5X0.8X12-MM)3
6C908135 LOCKWASHER4
129646636 SWITCH AS-ROLLER1
9X0199BOOT-SWITCH1
2H3922LOCKWASHER1
6V8363SCREW (10-32X0.312-IN)1
6V8370NUT-HEX (3/4-32-THD)1
8F1434LOCKWASHER1
109127037 GROMMET2
121651838 GROMMET1
6C912139 BRACKET AS-LAMP1
6C912240 LAMP (24-VOLT)2
151938541 MONITOR GP-OPERATOR1
1712655COVER1
1573122KIT-BACKUP ALARM1
9W149442 KIT-SERVICE METER (24-VOLT)1
139530743 COVER AS-MONITOR1
141398044 SUPPORT AS1
6V9632NUT-WELD (M6X1-THD)1
112330945 CLAMP2
158092046 HOSE1
109125447 NOZZLE-AIR1
6C905848 SCREW (M6X1X12-MM)3
139603949 NUT-RETAINER (U-TYPE)3
9X204450 SCREW-TRUSS HEAD (M6X1X16-MM)3
6C914351 ARM AS1
6C910752 NOZZLE-WATER1
6C910853 HOSE-WATER1
6C910954 CLIP2
6C911055 ELBOW1
