145-8714 WIPER & WASHER GP-WINDOW -LOWERS/N 5SW1-UP

Group No: 145-8714
Part NumberPart NameQty
6W39241 BLADE AS-WIPER (558-MM)1
14556992 BRACKET AS1
8T41913 BOLT (M10X1.5X16-MM)4
8T41214 WASHER-HARD (11X21X2.5-MM THK)4
8T42005 BOLT (M8X1.25X16-MM)2
8T42246 WASHER-HARD (8.8X16X2-MM THK)4
13320037 ARM GP-WINDOW WIPER1
5C95538 BOLT (M6X1X16-MM)1
5C28909 NUT (M6X1-THD)1
9X825610 WASHER (6.6X12X2-MM THK)4
2V321611 CLIP (LOOP)1
131039812 MOTOR AS-WINDOW WIPER (LOWER)1
2D129013 GROMMET1
6C922114 NUT (M24X1.5-THD)1
135042915 LINK AS1
136576516 BOSS1
8T413817 BOLT (M6X1X20-MM)3
6C909718 NUT (M16X1-THD)1
145570319 BRACKET AS1
5C726120 NUT (M8X1.25-THD)2
3A904921 BUMPER1
