System And Components
118-9835 MUFFLER GPS/N 7JR1-UP; 1XS1-UP; 2AS1-UP; 5MS1-UP; 9WS1-UP; 6LW1-UP; 3YZ1-UP
Group No: 118-9835
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1189906 | 1 MUFFLER AS | 1 | |
| 7Y1518 | 2 U-BOLT | 2 | |
| 7S8735 | 3 CLAMP | 1 | |
| 7Y1517 | 4 PIPE AS-TAIL | 1 | |
| 8T4185 | 5 BOLT (M10X1.5X50-MM) | 1 | |
| 7Y1513 | 6 PIPE AS-EXHAUST | 1 | |
| 7C0752 | 7 CLAMP | 1 | |
| 7Y0504 | 8 SUPPORT AS | 1 | |
| 8T4136 | 9 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4133 | 11 NUT (M10X1.5-THD) | 9 | |
| 7Y1523 | 12 PLATE | 1 | |
| 8T4137 | 13 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4195 | 14 BOLT (M10X1.5X30-MM) | 4 | |
| 7X7729 | 15 WASHER (11X25X3-MM THK) | 4 | |
| 7Y1519 | 16 BRACKET AS | 1 | |
| 7E3870 | 17 CLAMP-MUFFLER | 1 |
