System And Components
117-4392 PUMP GP-REFUELINGS/N 7JR1-UP; 1XS1-UP; 2AS1-UP; 5MS1-UP; 9WS1-UP; 6LW1-UP; 3YZ1-UP
Group No: 117-4392
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1317582 | 1 SUPPORT AS | 1 | |
| 5P0742 | 2 HOSE (300CM) | ||
| 2S3440 | 3 CLAMP-HOSE | 2 | |
| 5C0746 | 4 STRAINER GP-FUEL | 1 | |
| 5P0743 | 5 HOSE (60CM) | ||
| 6D3534 | 6 CONNECTOR-HOSE | 1 | |
| 0057898 | 7 CONNECTOR-HOSE | 1 | |
| 1K6937 | 8 ELBOW-PIPE | 1 | |
| 4I8443 | 9 VALVE-CHECK | 1 | |
| 1754807 | 10 PUMP & MOTOR GP | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 8T4192 | 11 BOLT (M12X1.75X25-MM) | 5 | |
| 5P1076 | 12 WASHER-HARD (13.5X30X4-MM THK) | 5 | |
| 5C6108 | 13 SWITCH GP-REFUELING (FUEL TANK SHUTOFF) | 1 | |
| 1224021 | 14 COVER | 1 | |
| 8T4195 | 15 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 1205114 | 17 FILM-INSTRUCTION (REFUELING PUMP) | 1 | |
| 5D1026 | 18 CLAMP-BAND | 2 |
