System And Components
201-1037 CYLINDER BLOCK ASS/N 5XK9971-UP
Group No: 201-1037
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D3118 | 1 PLUG-PIPE | 3 | |
| 5M6213 | 2 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9F2247 | 3 PLUG-PIPE (1/8-27-THD) | 8 | |
| 2344796 | 4 GASKET | 1 | |
| 1835916 | 5 PIN-SPRING | 6 | |
| 0963741 | 7 CAP | 9 | |
| 5I8009 | 8 BUSHING | 1 | |
| 5I7528 | 9 BUSHING | 2 | |
| 5I7529 | 10 BUSHING | 1 | |
| 3P1896 | 11 PLUG-CUP (35.31-MM OD) | 15 | |
| 3149938 | 12 BUSHING | 1 | |
| 2335488 | 13 PIN | 2 | |
| 1039276 | 14 BOLT | 14 | |
| 1039703 | 15 SHAFT-IDLER | 1 | |
| 1041218 | 16 DOWEL | 2 | |
| 5I7525 | 17 PLUG | 1 | |
| 1073667 | 18 PLUG | 1 | |
| 1073669 | 19 JET | 6 | |
| 2941767 | 20 VALVE (PRESSURE RELIEF)(ENGINE OIL) | 1 | |
| 0994420 | 21 PIN | 2 | |
| 5I4993 | 22 SEAL | 1 |
