System And Components
132-7791 CONTROL GP-GOVERNOR(V)
Group No: 132-7791
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C9553 | 1 BOLT (M6X1X16-MM) | 1 | |
| 9X8256 | 2 WASHER (6.6X12X2-MM THK) | 8 | |
| 4D8123 | 3 CLIP | 1 | |
| 0932068 | 4 GROMMET | 1 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4191 | 6 BOLT (M10X1.5X16-MM) | 4 | |
| 1573123 | 7 COVER AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 8T4224 | 8 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 5C7261 | 9 NUT (M8X1.25-THD) | 1 | |
| 1262961 | 10 LEVER AS | 1 | |
| 7X2534 | 11 BOLT (M6X1X50-MM) | 2 | |
| 8T4127 | 12 SCREW-MACHINE (M5X0.8X20-MM) | 3 | |
| 8T0328 | 13 WASHER-HARD (5.5X10X1-MM THK) | 3 | |
| 1262935 | 14 TIGHTENER | 3 | |
| 7Y9390 | 15 KNOB | 1 | |
| 1648236 | 16 MOTOR AS-GOVERNOR | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 1262957 | 17 BRACKET | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T4138 | 18 BOLT (M6X1X20-MM) | 2 | |
| 8M2770 | 19 CLIP | 2 | |
| 8T4137 | 20 BOLT (M10X1.5X20-MM) | 1 | |
| 1327764 | 21 CONTROL GP-GOVERNOR | 1 | |
| 1028810 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1028815 | SEAL | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 7 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 8T6411 | 22 SCREW-MACHINE (M6X1X12-MM) | 4 | |
| 9X6165 | 23 WASHER (6.5X22X2.5-MM THK) | 1 |
