System And Components
178-1049 PUMP GP-FUELPART OF 178-1048 PUMP AR-FUEL TRANSFER
Group No: 178-1049
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6B9081 | 1 BUSHING-REDUCING | 1 | |
| 0039163 | 2 ELBOW | 1 | |
| 6D3534 | 3 CONNECTOR-HOSE | 2 | |
| 2S3440 | 4 CLAMP-HOSE | 2 | |
| 1781057 | 5 SUPPORT AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 8T4192 | 6 BOLT (M12X1.75X25-MM) | 2 | |
| 5P1076 | 7 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 1224021 | 8 COVER | 1 | |
| 5C6108 | 9 SWITCH GP-REFUELING (FUEL TANK SHUTOFF) | 1 | |
| 5P0743 | 10 HOSE (105CM) | ||
| 5P0742 | 11 HOSE (350CM) | ||
| 1754807 | 12 PUMP & MOTOR GP | 1 | |
| 8T4908 | 13 BOLT (M8X1.25X25-MM) | 2 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1205114 | 15 FILM-INSTRUCTION (REFUELING PUMP) | 1 | |
| 7Y3281 | 16 GROMMET | 1 | |
| 3B6490 | 17 COUPLING-PIPE | 1 | |
| 4I8443 | 18 VALVE-CHECK | 1 | |
| 1186731 | 19 CAP AS | 1 | |
| 5C0746 | 20 STRAINER GP-FUEL | 1 | |
| 0057898 | 21 CONNECTOR-HOSE | 1 | |
| 5D1026 | 22 CLAMP-BAND | 2 |
