System And Components
169-0581 PANEL GP-CIRCUIT BREAKERPART OF 169-2477 BATTERY & WIRING GP
Group No: 169-0581
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4191 | 1 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4121 | 2 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 1343316 | 3 COVER | 1 | |
| 1709372 | 4 COVER | 1 | |
| 8T6411 | 5 SCREW-MACHINE (M6X1X12-MM) | 17 | |
| 9X8256 | 6 WASHER (6.6X12X2-MM THK) | 26 | |
| 8T0328 | 7 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 1400866 | 8 RELAY (24-VOLT) | 8 | |
| 7Y5493 | 9 TOOL (FUSE PULLER) | 1 | |
| 9W1442 | 10 FUSE (10-AMPERE) | 14 | |
| 9W1441 | 11 FUSE (15-AMPERE) | 4 | |
| 8T9636 | 12 FUSE (30-AMPERE) | 2 | |
| 5C9553 | 13 BOLT (M6X1X16-MM) | 2 | |
| 5C2890 | 14 NUT (M6X1-THD) | 4 | |
| 1321817 | 15 TIMER AS-OFF DELAY | 1 | |
| 7X2619 | 16 BOLT (M6X1X10-MM) | 1 | |
| 0855353 | 17 SWITCH GP-MAGNETIC | 1 | |
| 5C2890 | NUT (M6X1-THD) | 2 | |
| 8C7581 | SCREW-MACHINE (M4X0.7X8-MM) | 1 | |
| 9X8256 | WASHER (6.6X12X2-MM THK) | 2 | |
| 0950826 | LOCKWASHER | 1 | |
| 0966166 | WASHER-HARD (4.5X9X1-MM THK) | 1 | |
| 1321862 | FUSE (127-AMPERE) | 1 | |
| 0948059 | 18 SWITCH AS-SOLENOID (START RELAY) | 1 | |
| 1059982 | 19 CLIP | 2 | |
| 8C7581 | 20 SCREW-MACHINE (M4X0.7X8-MM) | 4 | |
| 0966166 | 21 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 1059985 | 22 CLIP | 2 | |
| 3S2093 | 23 STRAP-CABLE | 4 | |
| 0950742 | 24 SCREW-MACHINE (M6X1X16-MM) | 2 | |
| 1385190 | 25 CONTROL GP-ENGINE ELECTRONIC (ENGINE SHUTDOWN) | 1 | |
| 1225545 | 26 RELAY | 1 | |
| 1343322 | 27 WIRE AS | 1 | |
| 1343321 | 28 WIRE AS | 1 | |
| 1343320 | 29 WIRE AS | 1 | |
| 1343318 | 30 WIRE AS | 1 | |
| 7Y5499 | 31 BLOCK AS-TERMINAL | 1 | |
| 9S0174 | 32 CIRCUIT BREAKER AS (60-AMPERE) | 1 | |
| 1H3244 | LOCKWASHER | 2 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 6V5645 | 33 SCREW-MACHINE (10-32X0.87-IN) | 2 | |
| 1532582 | 34 WIRE AS | 1 | |
| 1532583 | 35 WIRE AS | 1 | |
| 1690582 | 36 HARNESS AS | 1 | |
| 1532611 | 37 BRACKET AS | 1 | |
| 1709373 | 38 LATCH | 2 |
