System And Components
180-4180 HOOD & GUARD GPS/N AFB1352-UP
Group No: 180-4180
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1589336 | 1 SUPPORT AS | 1 | |
| 1351460 | LINER | 1 | |
| 1467025 | 2 SHEET AS | 1 | |
| 1467026 | SEAL | 1 | |
| 1351475 | 3 SUPPORT AS | 1 | |
| 1449348 | 4 SHEET AS | 1 | |
| 1351479 | 5 ANGLE | 1 | |
| 1467016 | 6 SHEET AS | 1 | |
| 1467017 | INSULATION | 1 | |
| 1467024 | 7 SUPPORT AS | 1 | |
| 1351484 | 8 SHEET AS | 1 | |
| 1467018 | 9 COVER AS | 1 | |
| 1420963 | HINGE | 2 | |
| 1467019 | INSULATION | 1 | |
| 1467020 | INSULATION | 1 | |
| 1351487 | 10 SHEET AS | 1 | |
| 1351489 | 11 SHEET AS | 1 | |
| 1466938 | 12 SHEET AS | 1 | |
| 1351494 | LINER | 1 | |
| 1511642 | SEAL | 2 | |
| 1449349 | 13 SHEET | 1 | |
| 1467021 | 14 COVER AS | 1 | |
| 1467019 | INSULATION | 1 | |
| 1467020 | INSULATION | 1 | |
| 1511617 | 15 COVER | 1 | |
| 2100785 | 16 HOOD GP-ENGINE | 1 | |
| 8T4139 | 17 BOLT (M12X1.75X30-MM) | 18 | |
| 1273266 | 18 SPRING-GAS | 2 | |
| 1847833 | 19 PLATE | 1 | |
| 1837338 | 20 BRACKET | 2 | |
| 1948526 | 21 BRACKET | 2 | |
| 5P1076 | 22 WASHER-HARD (13.5X30X4-MM THK) | 65 | |
| 1420967 | 23 BRACKET | 1 | |
| 8T4137 | 24 BOLT (M10X1.5X20-MM) | 4 | |
| 7X7729 | 25 WASHER (11X25X3-MM THK) | 6 | |
| 8T4186 | 26 BOLT (M10X1.5X40-MM) | 2 | |
| 5C9553 | 27 BOLT (M6X1X16-MM) | 8 | |
| 9X8256 | 28 WASHER (6.6X12X2-MM THK) | 8 | |
| 1351496 | 29 SHEET | 1 | |
| 1420965 | 30 SHEET AS | 1 | |
| 1467027 | 31 BRACKET AS | 1 | |
| 1466933 | 32 SHEET AS | 1 | |
| 1466937 | LINER | 1 | |
| 8T4223 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 11 | |
| 0878894 | 34 SHIM (2-MM THK) | 2 | |
| 0878895 | 35 SHIM (1-MM THK) | 2 | |
| 0878896 | 36 SHIM (0.5-MM THK) | 2 | |
| 0960684 | 37 SHIM (0.8-MM THK) | 2 | |
| 1025689 | 38 SHIM (2-MM THK) | 2 | |
| 1511526 | 39 SHIM (3-MM THK) | 3 | |
| 1511527 | 40 SHIM (2-MM THK) | 2 | |
| 1511528 | 41 SHIM (1-MM THK) | 1 | |
| 8T4183 | 42 BOLT (M12X1.75X40-MM) | 2 | |
| 1449313 | 43 SHEET AS | 1 | |
| 1802678 | 44 SHEET AS | 1 | |
| 1025673 | 45 ROD | 1 | |
| 8T4192 | 46 BOLT (M12X1.75X25-MM) | 41 | |
| 1589331 | 47 BRACKET AS | 1 | |
| 1589333 | 48 BRACKET AS | 1 | |
| 2138536 | 49 SHIM (3-MM THK) | 3 | |
| 2138535 | 50 SHIM (1-MM THK) | 1 | |
| 1802691 | 51 BRACKET | 2 | |
| 8T4179 | 52 BOLT (M12X1.75X20-MM) | 10 | |
| 6V8547 | 53 PLUG-BUTTON | 4 | |
| 1807322 | 54 BRACKET | 1 | |
| 8T4194 | 55 BOLT (M12X1.75X50-MM) | 3 | |
| 1805913 | 56 PLATE | 1 | |
| 7Y8166 | 57 GROMMET | 1 | |
| 1847834 | 58 BRACE AS | 1 | |
| 5C7261 | 59 NUT (M8X1.25-THD) | 4 | |
| 2154559 | 60 PLATE AS | 1 | |
| 8T4224 | 61 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 0950843 | 62 PIN-COTTER | 1 | |
| 0963780 | 63 PIN-CLEVIS | 1 | |
| 8T4956 | 64 BOLT (M12X1.75X35-MM) | 2 | |
| 1837336 | 65 SHIM (1-MM THK) | 1 | |
| 1837335 | 66 SHIM (3-MM THK) | 1 |
