System And Components
210-0785 HOOD GP-ENGINES/N AFB1352-UP
Group No: 210-0785
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7I1639 | 1 PIN | 2 | |
| 1391603 | 2 SEAL | 1 | |
| 2105512 | 3 SPACER (10.5X15.0X3.5-MM THK) | 8 | |
| 2154560 | 4 LATCH AS | 1 | |
| 2260294 | LOCK AS | 1 | |
| 2154557 | PAWL | 1 | |
| 2190196 | 5 LINER | 1 | |
| 2190200 | 6 FRAME AS | 1 | |
| 2190201 | 7 LINER | 1 | |
| 2190202 | 8 LINER | 1 | |
| 2190203 | 9 LINER | 1 | |
| 2190204 | 10 BUMPER | 1 | |
| 2201542 | 11 INSULATION | 1 | |
| 2201543 | 12 INSULATION | 1 | |
| 2201544 | 13 INSULATION | 1 | |
| 2201545 | 14 INSULATION | 1 | |
| 2201546 | 15 INSULATION | 1 | |
| 2201547 | 16 INSULATION | 1 | |
| 2201548 | 17 INSULATION | 1 | |
| 2201549 | 18 INSULATION | 1 | |
| 2201550 | 19 HOOD | 1 | |
| 5P1076 | 20 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V7743 | 21 LOCKNUT (M6X1-THD) | 5 | |
| 7X7729 | 22 WASHER (11X25X3-MM THK) | 12 | |
| 8T4191 | 23 BOLT (M10X1.5X16-MM) | 12 | |
| 9X2045 | 24 SCREW-TRUSS HEAD (M6X1X20-MM) | 5 | |
| 9X8256 | 25 WASHER (6.6X12X2-MM THK) | 5 |
