System And Components
7N-8966 DRIVE GP-FAN -SUCTIONS/N 78Z4867-99999
Group No: 7N-8966
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N7688 | 1 BRACKET AS-FAN | 1 | |
| 4N0684 | 1A DOWEL | 1 | |
| 1P9946 | 1B SHAFT-FAN | 1 | |
| 6N2547 | 2 ADAPTER-FAN BRACKET | 1 | |
| 1F7960 | 3 WASHER (13.5X32X6-MM THK) | 4 | |
| 9L0553 | 4 STUD-TAPERLOCK (1/2-13X4.25-IN) | 4 | |
| 6N2538 | 5 BRACKET-FAN ADJUSTMENT | 1 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 2 | |
| 1D4717 | 7 NUT (3/8-16-THD) | 1 | |
| 8L5213 | 8 BOLT (3/8-16X4-IN) | 1 | |
| 5S9062 | 9 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 8H9789 | 10 BALL BEARING | 1 | |
| 8N5305 | 11 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 3L1425 | 12 BALL BEARING | 1 | |
| 7N2900 | 13 RETAINER | 1 | |
| 5P7979 | 14 BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 5S2106 | 15 SEAL-LIP TYPE | 1 | |
| 4N3123 | 16 ADAPTER-FAN | 1 | |
| 9F4446 | 17 SEAL-O-RING | 1 | |
| 7N8827 | 18 HUB | 1 | |
| 6N0597 | 19 PULLEY-FAN DRIVE (4-GROOVE) | 1 | |
| 0L2070 | 20 BOLT (3/8-16X2.25-IN) | 6 | |
| 1B5174 | 21 PLUG-PIPE | 1 | |
| 6N6652 | 22 V-BELT SET (INCLUDES 3-BELTS)(FAN DRIVE) | 1 | |
| 4B4550 | 23 FITTING-PRESSURE RELIEF (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 1D4719 | 24 NUT-FULL (1/2-13-THD) | 4 | |
| 2D4867 | 25 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 |
