System And Components
Assembly
100%

8N-8379 LINES GP-TURBOCHARGER OILS/N 78Z4867-99999

Group No: 8N-8379
Part NumberPart NameQty
2B32431 CLIP2
0L13512 BOLT (3/8-16X0.875-IN)2
9S87523 NUT-FULL (3/8-16-THD)5
5M28944 WASHER-HARD (10.2X18.5X2.5-MM THK)2
6N90765 TUBE AS-OIL1
19860686 SEAL-INTEGRAL1
0S15717 BOLT (3/8-16X1.75-IN)2
1A20298 BOLT (3/8-16X1.125-IN)2
12627029 SEAL-INTEGRAL1
4N615910 TUBE AS-DRAIN1
458363911 ELBOW1
112354012 SEAL-O-RING1
6F701213 STUD-TAPERLOCK (3/8-16X1.57-IN)2
8N210214 SHIELD AS-HEAT1
0S050915 BOLT (3/8-16X0.75-IN)2
6M747616 ELBOW1
114442717 SEAL-O-RING1
9L132118 STUD-TAPERLOCK (3/8-16X1.18-IN)1
3L968919 WASHER (10.5X25.4X5-MM THK)2
8N839020 BRACKET1
9X645821 WASHER-HARD (10.2X22.5X3-MM THK)5
9L913222 WASHER-HARD (10.2X25.5X2.5-MM THK)2
9L692423 GASKET1
2N276624 LOCKNUT (3/8-16-THD)1
