System And Components
144-9353 PUMP GP-FUEL TRANSFERS/N 3LR1-UP; 7KZ1-UP
Group No: 144-9353
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1317582 | 1 SUPPORT AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 5P0742 | 2 HOSE (340 CM) | ||
| 2S3440 | 3 CLAMP-HOSE | 2 | |
| 5C0746 | 4 STRAINER GP-FUEL | 1 | |
| 5C0747 | COUPLING | 1 | |
| 5C0748 | STRAINER AS | 1 | |
| 0336783 | FITTING | 1 | |
| 5P0743 | 5 HOSE (80 CM) | ||
| 6D3534 | 6 CONNECTOR-HOSE | 1 | |
| 0057898 | 7 CONNECTOR-HOSE | 1 | |
| 1K6937 | 8 ELBOW-PIPE | 1 | |
| 4I8443 | 9 VALVE-CHECK | 1 | |
| 1233928 | 10 PUMP & MOTOR GP-FUEL TRANSFER | 1 | |
| 8T4192 | 11 BOLT (M12X1.75X25-MM) | 5 | |
| 5P1076 | 12 WASHER-HARD (13.5X30X4-MM THK) | 5 | |
| 5C6108 | 13 SWITCH GP-REFUELING (FUEL TANK SHUTOFF) | 1 | |
| 2L8076 | TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 4B2049 | NUT (10-32-THD) | 2 | |
| 5C6074 | FITTING | 1 | |
| 8J9236 | SWITCH (LIQUID LEVEL) | 1 | |
| 8S1812 | TERMINAL | 1 | |
| 8S1814 | INSULATOR | 2 | |
| 8S1815 | PLUG | 1 | |
| 9B4499 | SCREW-MACHINE (8-36X0.375-IN) | 1 | |
| 1224021 | 14 COVER | 1 | |
| 8T4195 | 15 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 1205114 | 17 FILM-INSTRUCTION (REFUELING PUMP) | 1 | |
| 1351441 | 18 SHEET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 5D1026 | 19 CLAMP-BAND | 2 |
