System And Components
135-6531 CYLINDER HEAD GPS/N BET1-7998
Group No: 135-6531
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1078618 | 1 SENSOR GP-TEMPERATURE (INLET AIR) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1124550 | SLEEVE (31-CM) | ||
| 1946724 | 2 SENSOR GP-PRESSURE (TURBOCHARGER OUTLET) | 1 | |
| 8T6763 | 3 PLUG-PIPE (1/4-18-THD) | 1 | |
| 2245122 | 4 GASKET (CYLINDER HEAD) | 1 | |
| 1835296 | 5 CYLINDER HEAD GP | 1 | |
| 1948124 | 6 SLEEVE AS (EXHAUST PORT) | 6 | |
| 3E6772 | 7 SEAL (WATER) | 24 | |
| 6I4025 | 8 FASTENER GP-CYLINDER HEAD | 16 | |
| 1241855 | 8A BOLT-12 POINT HEAD (3/4-16X7.638-IN) | 1 | |
| 5H1504 | 8B WASHER-HARD (20X33.5X5-MM THK) | 1 | |
| 6V5048 | 9 SEAL-O-RING | 1 | |
| 6V5049 | 10 SEAL-O-RING | 5 | |
| 1065673 | 11 FASTENER GP-CYLINDER HEAD | 10 | |
| 1241854 | 11A BOLT-12 POINT HEAD (3/4-16X8.5-IN) | 1 | |
| 5H1504 | 11B WASHER-HARD (20X33.5X5-MM THK) | 1 | |
| 8T6762 | 12 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8L2786 | 13 SEAL-O-RING | 1 | |
| 2P8421 | 14 ADAPTER-O-RING | 1 | |
| 0086817 | 15 ELBOW | 1 | |
| 9S8004 | 16 PLUG (9/16-18-THD) | 3 | |
| 5P0840 | 17 SEAL-O-RING | 1 | |
| 0303978 | 18 CONNECTOR | 1 | |
| 6V5050 | 19 SEAL-O-RING | 1 | |
| 1005725 | 20 STUD (3/8-16X1.25-IN) | 1 | |
| 8T4896 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T6765 | 22 PLUG-PIPE (1/4-18-THD) | 2 | |
| 9S4191 | 23 PLUG (9/16-18-THD) | 1 | |
| 9S4190 | 24 PLUG-O-RING (7/8-14-THD) | 1 | |
| 6V3251 | 25 SEAL-O-RING | 1 |
