160-0657 SHIELD GP-MANIFOLDS/N ALP1-419

Group No: 160-0657
Part NumberPart NameQty
15724791 PLATE2
17159352 SHIELD AS1
4K9097NUT-WELD (5/16-18-THD)3
17159363 SHIELD AS1
17159374 SHIELD AS1
4K9097NUT-WELD (5/16-18-THD)5
17159385 SHIELD AS1
6V5044NUT-WELD (5/16-18-THD)4
17169416 SHIELD AS1
4K9097NUT-WELD (5/16-18-THD)9
5K09067 BOLT (5/16-18X0.625-IN)3
5M30628 BOLT (3/8-16X0.75-IN)4
5P10759 WASHER-HARD (10.2X22.5X3-MM THK)4
5P411610 WASHER-HARD (8.8X20.5X2-MM THK)20
5P995911 BOLT (5/16-18X0.5-IN)1
6V271212 STUD16
6V818913 NUT (5/16-18-THD)16
221969314 SHIELD AS1
221969415 SHIELD AS1
221969516 SHIELD AS1
221969617 SHIELD AS1
