System And Components
146-2741 CYLINDER BLOCK GPS/N BET524-UP
Group No: 146-2741
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1422329 | 1 SEAL | 1 | |
| 2021261 | 2 CYLINDER BLOCK GP | 1 | |
| 1S9540 | 3 DOWEL | 1 | |
| 5P0840 | 4 SEAL-O-RING | 1 | |
| 7W6492 | 5 PLUG-PIPE (1/2-14-THD) | 4 | |
| 6I1055 | 6 DOWEL | 1 | |
| 4N0683 | 7 DOWEL | 2 | |
| 4N1650 | 8 DOWEL | 1 | |
| 6I4421 | 9 PLATE-SPACER | 1 | |
| 2271204 | 10 GASKET | 1 | |
| 8S9094 | 11 PLUG-ORIFICE | 1 | |
| 9S4190 | 12 PLUG-O-RING (7/8-14-THD) | 1 | |
| 1144427 | 13 SEAL-O-RING | 1 | |
| 7X7732 | 14 PLUG-PIPE | 5 | |
| 2500466 | 15 SEAL-O-RING | 2 | |
| 1946725 | 16 SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 1007399 | 17 PLUG | 2 | |
| 9X7378 | 18 SEAL-O-RING | 1 | |
| 6V5048 | 19 SEAL-O-RING | 1 | |
| 9S4182 | 20 PLUG (7/16-20-THD) | 1 | |
| 3E7448 | 21 CONNECTOR | 1 | |
| 2666038 | 22 DOWEL | 2 | |
| 6I4361 | INSERT-LINER SEAT (0.772-MM THK) | ||
| 9Y3368 | INSERT-LINER SEAT (0.822-MM THK) | ||
| 6I4362 | INSERT-LINER SEAT (0.872-MM THK) | ||
| 6I4363 | INSERT-LINER SEAT (1.555-MM THK) | ||
| 2W3815 | INSERT-LINER SEAT (1.605-MM THK) | ||
| 6I4364 | INSERT-LINER SEAT (1.655-MM THK) | ||
| 6I4365 | INSERT-LINER SEAT (2.66-MM THK) | ||
| 5N0093 | INSERT-LINER SEAT (2.71-MM THK) | ||
| 6I4366 | INSERT-LINER SEAT (2.76-MM THK) | ||
| 1010524 | INSERT-LINER SEAT (5.16-MM THK) | ||
| 1010523 | INSERT-LINER SEAT (5.21-MM THK) | ||
| 1010525 | INSERT-LINER SEAT (5.26-MM THK) |
