System And Components
159-3803 DRIVE GP-FAN -BELTS/N ARW1-UP
Group No: 159-3803
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4564 | 1 WASHER-RETAINING (17X54X25-MM THK) | 1 | |
| 2W6280 | 2 BRACKET AS-FAN | 1 | |
| 8N8980 | SHAFT-FAN | 1 | |
| 3B8485 | 3 ELBOW (FAN DRIVE) | 1 | |
| 7W6943 | 4 ADAPTER | 1 | |
| 8N8978 | 5 SPACER (40X53.98X20-MM THK) | 1 | |
| 8N8979 | 6 SPACER (42X54X90-MM THK) | 1 | |
| 8N8983 | 7 HUB-FAN PULLEY | 1 | |
| 8N9394 | 8 HOSE AS | 1 | |
| 1569688 | 10 SUPPORT-COMPRESSOR | 1 | |
| 1570319 | 11 PULLEY-FAN (3-GROOVE, 1-GROOVE) | 1 | |
| 1643780 | 12 V-BELT SET (INCLUDES 3-BELTS)(FAN) | 1 | |
| 9L6651 | V-BELT | 3 | |
| 5F0149 | 13 SEAL-O-RING | 1 | |
| 5P9297 | 14 CLIP (LOOP) | 1 | |
| 5S7382 | 15 BOLT (3/8-16X1.375-IN) | 6 | |
| 6H3956 | 16 PIN | 1 | |
| 6H3957 | 17 BALL BEARING | 2 | |
| 6V8188 | 18 NUT (1/2-13-THD) | 2 | |
| 7X7890 | 19 BOLT (5/8-11X9.5-IN) | 1 | |
| 8B8255 | 20 SEAL-LIP TYPE | 1 | |
| 8T2502 | 21 BOLT (3/8-16X1.125-IN) | 6 | |
| 8T4835 | 22 BOLT (1/2-13X2-IN) | 8 |
