System And Components
183-6564 BATTERY & WIRING GPS/N AXF1-634
Group No: 183-6564
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G4177 | 1 CABLE AS | 1 | |
| 5P0747 | CABLE (00-GA, BLACK) | ||
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 2G8767 | 2 WASHER (10.5X60X3-MM THK) | 6 | |
| 3D2367 | 3 TIE ROD | 4 | |
| 3E8320 | 4 PLATE-INSTRUCTION (BATTERY) | 1 | |
| 3S2093 | 5 STRAP-CABLE | 12 | |
| 5T3907 | 6 CLAMP | 4 | |
| 6G2256 | 7 CLAMP | 4 | |
| 6G2263 | 8 SPACER (10.5X19X28.5-MM THK) | 4 | |
| 8W0301 | 9 FLANGE | 2 | |
| 8W3293 | 10 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 8W8460 | 11 GUARD | 4 | |
| 8W8720 | 12 HOLD-DOWN AS | 1 | |
| 9G0549 | 13 CABLE AS | 2 | |
| 8C5917 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 2 | |
| 1M6120 | NUT (5/16-18-THD) | 2 | |
| 8T9757 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 9G0003 | COVER AS-TERMINAL (BLACK) | 1 | |
| 9G0004 | COVER AS-TERMINAL (RED) | 1 | |
| 1335091 | 14 RECEPTACLE AS (TRACTOR AUXILLARY START) | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 5P0747 | CABLE (00-GA, BLACK) | ||
| 5P0761 | CABLE (00-GA, RED) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 1676780 | 15 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 9S5754 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 7T4924 | COVER-TERMINAL (RED) | 1 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 1676781 | 16 CABLE AS | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 9S5755 | TERMINAL AS (NEGATIVE) | 1 | |
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 7T4925 | COVER-TERMINAL (BLACK) | 1 | |
| 9G8909 | COVER-TERMINAL (BLACK) | 1 | |
| 1676782 | 17 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 2 | |
| 8N0869 | COVER-TERMINAL (RED) | 2 | |
| 1676783 | 18 CABLE AS | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 2 | |
| 9G8909 | COVER-TERMINAL (BLACK) | 1 | |
| 1752771 | 19 PLATE AS | 1 | |
| 3T5760 | 20 BATTERY GP (12-VOLT, 750-CCA)(TRACTOR) | 4 | |
| 4K8302 | 21 CLIP (LOOP) | 1 | |
| 4L6454 | 22 BOLT (3/8-16X1-IN) | 4 | |
| 5M3062 | 23 BOLT (3/8-16X0.75-IN) | 2 | |
| 5P1075 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 7 | |
| 5P1076 | 25 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P2566 | 26 BOLT (1/2-13X1.5-IN) | 2 | |
| 5P8167 | 27 BOLT (3/8-16X0.625-IN) | 4 | |
| 5S7379 | 28 BOLT (3/8-16X0.875-IN) | 4 | |
| 6K8178 | 29 CLIP (LOOP) | 1 | |
| 6V0826 | 30 GROMMET | 1 | |
| 6V8188 | 31 NUT (1/2-13-THD) | 10 | |
| 7N0718 | 32 SWITCH GP-DISCONNECT (BATTERY) | 1 | |
| 7S3916 | 33 CLIP (TAB) | 1 | |
| 7S3919 | 34 CLIP (SLOT) | 1 | |
| 8C6358 | 35 BLOCK AS-JUNCTION (BATTERY)(CRANK/CHARGE) | 1 | |
| 1D5117 | NUT-JAM (1/2-13-THD) | 3 | |
| 8T3519 | BOLT-BRONZE (1/2-13X2-IN) | 3 | |
| 8S2634 | 36 COVER AS | 1 | |
| 2P2975 | SEAL-O-RING | 2 | |
| 8T2501 | 37 BOLT (3/8-16X2-IN) | 4 | |
| 8T4223 | 38 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4896 | 39 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 9X0941 | 40 LOCKNUT (1/2-13-THD) | 4 |
