System And Components
9W-2420 SENSOR GP-SPEED -TRANSMISSIONS/N 6PY1-UP
Group No: 9W-2420
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3696693 | 1 HOUSING-SENSOR | 1 | |
| 1B3867 | 2 BALL BEARING | 1 | |
| 9W7406 | 3 SHAFT | 1 | |
| 8H3981 | 4 RING-RETAINING | 1 | |
| 9W7334 | 5 ROTOR-SENSOR | 1 | |
| 2S6160 | 6 WASHER-HARD (10.2X32X5-MM THK) | 5 | |
| 3B1915 | 7 BOLT (3/8-16X1.375-IN) | 5 | |
| 6T5611 | 8 SPACER (9.75X17.5X16.25-MM THK) | 5 | |
| 9W7466 | 9 RETAINER | 1 | |
| 2A0762 | 10 BOLT (1/4-20X0.625-IN) | 4 | |
| 6T5613 | 11 SPACER (7.85-MM THK) | 1 | |
| 6T5612 | 12 GROMMET | 5 | |
| 5P0537 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 4 |
