System And Components
183-6567 WIRING GP-HITCHS/N AXF1-UP
Group No: 183-6567
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 9G9150 | 2 CLIP | 1 | |
| 9M2904 | 3 CLAMP-HOSE | 6 | |
| 9M7958 | 4 CLAMP-HOSE | 6 | |
| 1012746 | 5 GUARD | 1 | |
| 1068704 | 6 SUPPRESSOR AS-ARC | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN)(INCL RECEPTACLE AS & WEDGE) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1615774 | 7 HARNESS AS-CHASSIS | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1615775 | 8 HARNESS AS-REAR CHASSIS | 1 | |
| 3T0204 | RECEPTACLE AS-CONNECTOR (20-PIN) | 1 | |
| 8N1513 | RECEPTACLE AS-CONNECTOR (37-PIN) | 1 | |
| 8N1525 | PLUG AS-CONNECTOR (20-PIN) | 1 | |
| 8N1535 | BELL AS-END | 2 | |
| 8N1521 | BELL AS-END | 1 | |
| 1922898 | 9 GUARD | 1 | |
| 1091633 | 10 CLIP (SLOT) | 3 | |
| 1091634 | 11 CLIP (TAB) | 3 | |
| 1305300 | 12 CLIP | 1 | |
| 4L6454 | 13 BOLT (3/8-16X1-IN) | 1 | |
| 5M3062 | 14 BOLT (3/8-16X0.75-IN) | 3 | |
| 5P1075 | 15 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P7468 | 16 CLIP (SLOT) | 1 | |
| 5P7469 | 17 CLIP (TAB) | 1 | |
| 5P8182 | 18 GROMMET (46-MM ID) | 3 | |
| 5P8444 | 19 GROMMET (37-MM ID) | 1 | |
| 6V8801 | 20 NUT (3/8-16-THD) | 1 | |
| 8M2773 | 21 CLIP (LOOP) | 2 | |
| 8T4896 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 9B7237 | 23 BOLT (3/8-16X1.25-IN) | 1 | |
| 9M8406 | 24 CLIP (LOOP) | 2 |
