System And Components
169-4704 FENDER GPS/N AXF1-701
Group No: 169-4704
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A6924 | 1 SHIELD AS (LH) | 1 | |
| 2A6965 | 2 PLATE | 1 | |
| 8D6088 | 3 SHIELD AS (RH) | 1 | |
| 1013160 | 4 BAFFLE AS | 1 | |
| 6B1985 | RIVET | 7 | |
| 1013772 | 5 PLATE AS | 1 | |
| 1014229 | 6 STRIP | 1 | |
| 1014480 | 7 BAFFLE | 1 | |
| 1494628 | 8 BRACKET AS (RH) | 1 | |
| 1494629 | 9 BRACKET AS (LH) | 1 | |
| 1497437 | 10 FENDER AS (LH) | 1 | |
| 1497438 | 11 FENDER AS (RH) | 1 | |
| 1680214 | 12 TREAD | 1 | |
| 2V3726 | 13 BUMPER | 2 | |
| 3K2889 | 14 LOCKNUT (5/8-11-THD) | 6 | |
| 4L6454 | 15 BOLT (3/8-16X1-IN) | 8 | |
| 5M3062 | 16 BOLT (3/8-16X0.75-IN) | 15 | |
| 5P1075 | 17 WASHER-HARD (10.2X22.5X3-MM THK) | 7 | |
| 5P8167 | 18 BOLT (3/8-16X0.625-IN) | 6 | |
| 7X0449 | 19 NUT-FULL (7/8-9-THD) | 6 | |
| 7X0515 | 20 WASHER-HARD (17X35X5-MM THK) | 12 | |
| 7X0772 | 21 WASHER-HARD (10.2X25.5X2.5-MM THK) | 7 | |
| 8C6362 | 22 BOLT (5/8-11X2.75-IN) | 6 | |
| 8C6913 | 23 WASHER-HARD (24X41.5X4-MM THK) | 6 | |
| 8T2501 | 24 BOLT (3/8-16X2-IN) | 6 | |
| 8T4896 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 8T4897 | 26 WASHER (10.2X35X6-MM THK) | 14 | |
| 9B7237 | 27 BOLT (3/8-16X1.25-IN) | 5 | |
| 1906472 | 28 PLATE AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 |
