169-4704 FENDER GPS/N AXF702-UP

Group No: 169-4704
Part NumberPart NameQty
2A69241 SHIELD AS (LH)1
2A69652 PLATE1
8D60883 SHIELD AS (RH)1
10131604 BAFFLE AS1
10137735 PLATE1
10142296 STRIP1
10144807 BAFFLE1
14946288 BRACKET AS (RH)1
14946299 BRACKET AS (LH)1
149743710 FENDER AS (LH)1
149743811 FENDER AS (RH)1
2V372612 BUMPER2
3K288913 LOCKNUT (5/8-11-THD)6
4L645414 BOLT (3/8-16X1-IN)6
5M306215 BOLT (3/8-16X0.75-IN)11
5P107516 WASHER-HARD (10.2X22.5X3-MM THK)1
5P816717 BOLT (3/8-16X0.625-IN)6
7X044918 NUT-FULL (7/8-9-THD)6
7X051519 WASHER-HARD (17X35X5-MM THK)12
7X077220 WASHER-HARD (10.2X25.5X2.5-MM THK)7
8C636221 BOLT (5/8-11X2.75-IN)6
8C691322 WASHER-HARD (24X41.5X4-MM THK)6
8T250123 BOLT (3/8-16X2-IN)6
8T489624 WASHER-HARD (10.2X18.5X2.5-MM THK)12
8T489725 WASHER (10.2X35X6-MM THK)14
9B723726 BOLT (3/8-16X1.25-IN)5
