8X-4981 HITCH GP-CUSHIONS/N AXF1-UP

Group No: 8X-4981
Part NumberPart NameQty
2J56371 PIN1
3G78532 RETAINER7
3G78943 LINK AS2
7J8458BUSHING4
3H52404 NUT (2-3/4-12-THD)1
4H26865 RING2
4J56896 WASHER (4X7.75X0.308-IN THK)1
4J56907 WASHER (5.38X7.75X0.308-IN THK)1
4J56918 WASHER (101.6X196.85X6.32-MM THK)1
5T08479 BRACKET1
5T103510 LINK AS-FRONT STEERING2
9J1676BUSHING4
5T332311 PIN AS2
5T464812 STUD-TAPERLOCK (3/4-10-THD)2
5T464913 SPACER-SPECIAL4
5T852614 PIN AS2
5T852815 PIN AS4
5T962716 RETAINER AS1
6G515517 BEARING-THRUST2
8J063218 PIN4
8J772719 PIN1
8W449620 RETAINER1
8X775821 FRAME AS1
8J759621A BUSHING2
102144421B BEARING2
9J942721C BUSHING4
9J217122 SPACER (69.8X73X68.6-MM)2
9J232323 WASHER (2.5X5X0.26-IN THK)2
102144024 RETAINER1
102144225 RETAINER1
102144326 RETAINER1
102144527 BRACKET AS1
5J661127A BUSHING2
9J942727B BUSHING4
143332127C BUSHING1
110774028 LINK-REAR STEERING2
148346529 PIN1
102144130 RETAINER2
1K687031 LOCKNUT (3/4-10-THD)2
3B462732 PIN-COTTER1
4J569233 WASHER-THRUST (4X6.81X0.249-IN THK)1
5T852534 PLATE4
6V884935 BOLT-12 POINT HEAD (3/4-10X3-IN)4
7D164936 WASHER-HARD (13.5X32X5-MM THK)6
7J366337 WASHER-THRUST8
8C443638 BOLT (1/2-13X1.375-IN)56
8T412239 WASHER-HARD (17X32X3.5-MM THK)4
8T422340 WASHER-HARD (13.5X25.5X3-MM THK)62
8T499441 WASHER-HARD (20X36.5X3.5-MM THK)6
8T891742 BOLT (1/2-13X1.25-IN)8
8T892043 BOLT (1/2-13X3.25-IN)4
8T939344 BOLT (5/8-11X1.5-IN)4
8T939945 BOLT (3/4-10X2.25-IN)2
8W951746 SPACER (71.5X120X3-MM THK)1
