155-1662 HOOD GP-TRACTORS/N AXF1-698

Group No: 155-1662
Part NumberPart NameQty
2G87681 WASHER (10.5X53.8X3-MM THK)1
4D60822 BOLT (1/2-13X1.5-IN)3
5T80623 ROD AS1
0T0431WASHER (10.3X19X2.5-MM THK)1
2G8768WASHER (10.5X53.8X3-MM THK)1
7V60644 BOLT AS8
7X13875 WASHER (10.26X22.22X1.9-MM THK)2
8K10776 SHIM (0.84-MM THK)4
14107337 ROD1
15516618 HOOD GP-TRACTOR1
16306029 GRILL AS1
164190110 ANGLE AS1
1F0748NUT-WELD (1/2-13-THD)2
165831511 PLATE AS2
1F0750NUT-WELD (3/8-16-THD)2
166665112 PLATE1
167118913 SPACER AS3
5V7190WASHER-HARD (10.5X45.2X6-MM THK)1
1327551SPACER (11X19X6-MM THK)1
055210214 PLUG2
3B461015 PIN-COTTER3
3B461516 PIN-COTTER4
4L645417 BOLT (3/8-16X1-IN)19
4M528118 BOLT (1/4-20X0.75-IN)6
5M306219 BOLT (3/8-16X0.75-IN)6
5P107520 WASHER-HARD (10.2X22.5X3-MM THK)19
5P107621 WASHER-HARD (13.5X30X4-MM THK)7
5P411522 WASHER-HARD (7.2X19X2-MM THK)8
5P843923 GROMMET1
5S734924 BOLT (1/4-20X0.5-IN)6
5S737925 BOLT (3/8-16X0.875-IN)4
5V719026 WASHER-HARD (10.5X45.2X6-MM THK)3
6N874427 MOUNT6
6N886328 WASHER (10.2X32X2.5-MM THK)6
6V880129 NUT (3/8-16-THD)1
8T250230 BOLT (3/8-16X1.125-IN)8
8T420531 WASHER-HARD (7.2X14.5X2-MM THK)4
8T422232 WASHER-PLATED (11X32X2.5-MM THK)4
8T489633 WASHER-HARD (10.2X18.5X2.5-MM THK)19
8T891734 BOLT (1/2-13X1.25-IN)4
9B723735 BOLT (3/8-16X1.25-IN)9
5P567036 SEAL
