215-2128 HOOD GP-TRACTORS/N AXF699-UP

Group No: 215-2128
Part NumberPart NameQty
2G87681 WASHER (10.5X53.8X3-MM THK)1
4D60822 BOLT (1/2-13X1.5-IN)3
5T80623 ROD AS1
0T0431WASHER (10.3X19X2.5-MM THK)1
2G8768WASHER (10.5X53.8X3-MM THK)1
7V60644 BOLT AS8
7X13875 WASHER (10.26X22.22X1.9-MM THK)2
8K10776 SHIM (0.84-MM THK)4
14107337 ROD1
21606078 GRILL AS1
16583159 PLATE AS2
1F0750NUT-WELD (3/8-16-THD)2
166665110 PLATE1
167118911 SPACER AS (11X19X6MM THK)3
5V7190WASHER-HARD (10.5X45.2X6-MM THK)1
215212712 HOOD GP-TRACTOR1
217339013 ANGLE AS1
1F0748NUT-WELD (1/2-13-THD)2
5B1983BOSS (3/8-16-THD)3
5H9394BOSS (1/2-13X1-IN)1
055210214 PLUG2
3B461015 PIN-COTTER3
3B461516 PIN-COTTER4
4L645417 BOLT (3/8-16X1-IN)19
5M306218 BOLT (3/8-16X0.75-IN)6
5P107519 WASHER-HARD (10.2X22.5X3-MM THK)15
5P107620 WASHER-HARD (13.5X30X4-MM THK)7
5P411521 WASHER-HARD (7.2X19X2-MM THK)2
5P852222 GROMMET1
5S734923 BOLT (1/4-20X0.5-IN)6
5S737924 BOLT (3/8-16X0.875-IN)4
5V719025 WASHER-HARD (10.5X45.2X6-MM THK)3
6N874426 MOUNT6
6N886327 WASHER (10.2X32X2.5-MM THK)6
6V880128 NUT (3/8-16-THD)1
8T250229 BOLT (3/8-16X1.125-IN)8
8T420530 WASHER-HARD (7.2X14.5X2-MM THK)4
8T422231 WASHER-PLATED (11X32X2.5-MM THK)4
8T489632 WASHER-HARD (10.2X18.5X2.5-MM THK)23
8T891733 BOLT (1/2-13X1.25-IN)4
9B723734 BOLT (3/8-16X1.25-IN)9
5P567035 SEAL (.8M)
