System And Components
6E-4069 VALVE GP-STEERINGS/N AXF1-UP
Group No: 6E-4069
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N4423 | 1 PLUG | 1 | |
| 1U4016 | 2 COVER | 1 | |
| 1U4053 | 3 VALVE GP-CHECK & RELIEF | 1 | |
| 1U4714 | 5 SHIM (0.12-MM THK) | 1 | |
| 1U4715 | 6 STRAINER | 1 | |
| 1U4716 | 7 SPACER (121.4-MM THK) | 1 | |
| 2L9625 | 8 SPRING | 1 | |
| 3G8648 | 9 VALVE GP-PRESSURE REDUCING (STEERING) | 1 | |
| 4F7115 | 10 SPRING | 1 | |
| 6D1601 | 12 SPRING | 1 | |
| 6J7240 | 15 SPRING | 1 | |
| 7M8538 | 17 SPACER (0.9-MM THK) | 3 | |
| 8B3115 | 18 SHIM (0.25-MM THK) | 4 | |
| 8J0245 | 19 SPRING | 1 | |
| 8J2634 | 20 SPRING | 1 | |
| 8J3660 | 21 RETAINER | 1 | |
| 8J3661 | 22 RETAINER | 1 | |
| 8J3662 | 23 SPACER (4.8-MM THK) | 1 | |
| 8J6815 | 24 PLUG-ORIFICE | 1 | |
| 8L2655 | 25 PLUG-PIPE | 1 | |
| 8M8211 | 26 SPACER (0.25-MM THK) | 1 | |
| 9F2167 | 27 SCREW-PURGE (3/8-24X1.164-IN) | 2 | |
| 9T1495 | 28 COVER | 1 | |
| 9T2999 | 29 VALVE | 1 | |
| 9T7202 | 30 RETAINER AS | 1 | |
| 9X6395 | 31 NUT (3/4-16-THD) | 1 | |
| 1331480 | 32 SPACER (15-MM THK) | 1 | |
| 1428538 | 33 VALVE GP-RELIEF (STEERING) | 1 | |
| 1488407 | 34 PLUG AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488409 | 35 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 | |
| 1488410 | 36 PLUG AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 1645567 | 37 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1733993 | 38 PLUG AS | 8 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 1P4577 | 39 FLANGE-HALF | 4 | |
| 1P4578 | 40 FLANGE-HALF | 4 | |
| 1P5763 | 41 FLANGE-HALF | 2 | |
| 2078218 | 42 PLUG AS | 2 | |
| 7J0204 | SEAL-O-RING | 1 | |
| 9S8007 | PLUG (3/8-24-THD) | 1 | |
| 3H2549 | 43 SHIM (0.254-MM THK) | 5 | |
| 3J7470 | 44 SHIM (1.22-MM THK) | 9 | |
| 3K0360 | 45 SEAL-O-RING | 2 | |
| 3P0439 | 46 SEAL-O-RING | 1 | |
| 4J0522 | 47 SEAL-O-RING | 1 | |
| 4J0524 | 48 SEAL-O-RING | 1 | |
| 4J0525 | 49 SEAL-O-RING | 2 | |
| 4J0526 | 50 SEAL-O-RING | 2 | |
| 4J0528 | 51 SEAL-O-RING | 1 | |
| 4J5309 | 52 SEAL-O-RING | 10 | |
| 5H4020 | 53 COVER | 1 | |
| 5P3108 | 54 SEAL-O-RING | 1 | |
| 5S7382 | 55 BOLT (3/8-16X1.375-IN) | 8 | |
| 6D0119 | 56 BOLT-SOCKET HEAD (1/2-13X3.25-IN) | 1 | |
| 6J2680 | 57 SEAL-O-RING | 1 | |
| 6V0852 | 58 CAP-DUST | 1 | |
| 2416215 | 59 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8076 | ELBOW | 1 | |
| 7X0277 | 60 BOLT (5/16-18X3.75-IN) | 2 | |
| 8T4223 | 61 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4835 | 62 BOLT (1/2-13X2-IN) | 9 | |
| 8T4896 | 63 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 8T5360 | 64 WASHER (12X22.5X2.5-MM THK) | 8 | |
| 8T8912 | 65 BOLT (5/16-18X2.25-IN) | 4 | |
| 8T8916 | 66 BOLT (7/16-14X1.5-IN) | 8 | |
| 8T9391 | 67 BOLT (1/2-13X3.75-IN) | 6 | |
| 9J9821 | 68 SEAT | 1 |
