System And Components
232-3790 CONTROL & MTG GP-JOYSTICKS/N AXF1-UP
Group No: 232-3790
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3261555 | 1 KIT-SERVICE | 1 | |
| 1892305 | 2 DETENT GP-CONTROL | 1 | |
| 1514977 | WASHER (4.445X9.525X1.092-MM THK) | 4 | |
| 1934476 | SCREW-PAN HEAD (M4X0.7X35-MM) | 4 | |
| 1924658 | 3 SCREW-PAN HEAD (M4X0.7X20-MM) | 4 | |
| 2572531 | 4 SENSOR GP-POSITION (JOYSTICK, BOWL) | 1 | |
| 2572532 | 5 SENSOR-POSITION (JOYSTICK, EJECTOR) | 1 | |
| 1934476 | 6 SCREW-PAN HEAD (M4X0.7X35-MM) | 8 | |
| 2309072 | 7 CONTROL GP-HANDLE (LIFT, TILT, AUXILIARY, AUTODIG) | 1 | |
| 2276718 | 8 DETENT GP-CONTROL (BOWL) | 1 | |
| 1514977 | 9 WASHER (4.445X9.525X1.092-MM THK) | 12 | |
| 1753265 | 10 SCREW (8-16X0.63-IN) | 1 | |
| 2K4898 | 11 CLAMP-TUBE | 1 | |
| 4B9808 | 12 SETSCREW (1/4-20X0.5-IN) | 2 | |
| 1743091 | 13 KIT-RECEPTACLE (12-PIN) | 1 | |
| 1863735 | 14 PIN-CONNECTOR (16-GA TO 18-GA) | 11 | |
| 8T8737 | 15 PLUG-SEAL | 1 | |
| 2086081 | 16 SLEEVE | 1 | |
| 3201220 | 17 KIT-SERVICE (CONTROL HANDLE) | 1 |
