Assembly
100%

363-9935 CONTROL & MTG GP-JOYSTICKS/N AXF1-UP

Group No: 363-9935
Part NumberPart NameQty
32615551 KIT-SERVICE1
18923052 DETENT GP-CONTROL1
19246583 SCREW-PAN HEAD (M4X0.7X20-MM)4
19344764 SCREW-PAN HEAD (M4X0.7X35-MM)8
22767185 DETENT GP-CONTROL1
1514977WASHER (4.445X9.525X1.092-MM THK)4
1934476SCREW-PAN HEAD (M4X0.7X35-MM)4
23090726 CONTROL GP-HANDLE (LIFT, TILT, AUXILIARY, AUTODIG)1
35169427 SENSOR GP-POSITION1
35169438 SENSOR GP-POSITION1
15149779 WASHER (4.445X9.525X1.092-MM THK)12
175326510 SCREW (8-16X0.63-IN)1
2K489811 CLAMP-TUBE1
4B980812 SETSCREW (1/4-20X0.5-IN)2
174309113 KIT-RECEPTACLE (12-PIN)1
8T872914 PIN-CONNECTOR (16-GA TO 20-GA)11
8T873715 PLUG-SEAL1
102880116 KIT-RECEPTACLE (12-PIN)1
208608117 SLEEVE1
320122018 KIT-SERVICE1
