System And Components
154-2481 DASH GPS/N AXF1-UP
Group No: 154-2481
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6924 | 1 SCREW-TRUSS HEAD (M6X1X50-MM) | 2 | |
| 8C0618 | 2 ASHTRAY AS | 1 | |
| 8Y6388 | 3 LOUVER AS-VENT | 5 | |
| 1293178 | 4 LOCKNUT (M6X1-THD) | 6 | |
| 1622321 | 5 PLENUM | 1 | |
| 1622323 | 6 COVER | 1 | |
| 1622324 | 7 PLENUM | 1 | |
| 1622325 | 8 COVER | 1 | |
| 1622326 | 9 COVER | 1 | |
| 1622327 | 10 COVER | 1 | |
| 1622330 | 11 COVER | 1 | |
| 1842535 | 12 DOOR AS | 1 | |
| 7M1530 | RIVET-POP | 11 | |
| 1588581 | HINGE AS | 1 | |
| 1882702 | LATCH AS | 1 | |
| 3H0240 | WASHER (5X9.7X0.8-MM THK) | 11 | |
| 5P5930 | SEAL | ||
| 1872067 | 13 PLENUM AS | 1 | |
| 1843292 | SEAL | 1 | |
| 1843293 | SEAL | 1 | |
| 1843295 | SEAL | 1 | |
| 1012867 | 14 WASHER-HARD (7.2X25X2-MM THK) | 14 | |
| 1042091 | 15 SCREW-FLAT HEAD (6-20X0.5-IN) | 10 | |
| 2H6120 | 16 SCREW-MACHINE (10-24X0.75-IN) | 2 | |
| 3E8020 | 17 SCREW-TRUSS HEAD (M6X1X25-MM) | 2 | |
| 8T4205 | 18 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T0328 | 19 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 9X2038 | 20 WASHER (7X19X2-MM THK) | 28 | |
| 9X2042 | 21 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 9X2043 | 22 SCREW-TRUSS HEAD (M6X1X14-MM) | 30 | |
| 9X2045 | 23 SCREW-TRUSS HEAD (M6X1X20-MM) | 8 | |
| 9X2046 | 24 SCREW-TRUSS HEAD (M6X1X35-MM) | 4 | |
| 1876499 | KIT-SEAL | 1 |
