System And Components
155-3558 PANEL GP-INSTRUMENTS/N AXF1-UP
Group No: 155-3558
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E0109 | 1 PLUG (ROCKER SWITCH) | 2 | |
| 3S2093 | 2 STRAP-CABLE | 5 | |
| 3T0304 | 3 BASE AS-INDICATOR LIGHT | 1 | |
| 6T7058 | 4 LENS (RED)(CATERPILLAR MONITORING SYSTEM) | 1 | |
| 7N1996 | 5 LAMP (24-VOLT)(CATERPILLAR MONITORING SYSTEM) | 1 | |
| 8Y6388 | 6 LOUVER AS-VENT | 2 | |
| 9W0335 | 7 LIGHTER AS-CIGAR (24-VOLT) | 1 | |
| 1005568 | 8 BEZEL | 1 | |
| 1071983 | 9 LAMP (24-VOLT)(INSTRUMENT) | 12 | |
| 1102079 | 10 LAMP (24-VOLT)(INSTRUMENT) | 4 | |
| 1106109 | 11 KNOB-CONTROL (HEAT/AC THERMOSTAT) | 1 | |
| 1107887 | 12 SWITCH AS-START (KEY) | 1 | |
| 3E3377 | WEDGE-RECEPTACLE LOCK (4-PIN) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1172311 | 13 SOCKET-AUXILIARY POWER (12-VOLT) | 1 | |
| 1274540 | 14 POTENTIOMETER AS (HEAT/AC THERMOSTAT) | 1 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1538061 | 15 MODULE GP-SPEEDOMETER & TACH | 1 | |
| 2038504 | 16 CONTROL GP-MONITOR (CATERPILLAR MONITORING SYSTEM) | 1 | |
| 1640956 | 17 HARNESS AS-PANEL | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN)(HEAT/AC CONTROL) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN)(KEY START) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN)(QUAD GAUGE & SPEEDO/TACH) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN)(CAT MONITORING SYSTEM GROUND) | 1 | |
| 8T9834 | PLUG AS-CONNECTOR (40-PIN)(CATERPILLAR MONITORING SYSTEM) | 1 | |
| 9X0141 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 9X7147 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 1648439 | 18 SWITCH AS-ROCKER (SCRAPER START) | 1 | |
| 1648440 | 19 SWITCH AS-ROCKER (DIAGNOSTIC MODE SELECT) | 1 | |
| 1648441 | 20 SWITCH AS-ROCKER (OVERSPEED TEST) | 1 | |
| 1648443 | 21 SWITCH AS-ROCKER (ETHER AID) | 1 | |
| 1648444 | 22 SWITCH AS-ROCKER (TRACTOR/SCRAPER SELECT) | 1 | |
| 1655963 | 23 SWITCH AS-ROCKER (HEAT/AC SELECT) | 1 | |
| 1655965 | 24 SWITCH AS-ROCKER (BLOWER SPEED) | 1 | |
| 1666674 | 25 MODULE | 2 | |
| 1682260 | 26 PLATE | 2 | |
| 1682262 | 27 PLATE AS | 1 | |
| 1686981 | 28 MODULE GP-QUAD GAUGE | 1 | |
| 1697494 | 29 FILM-IDENTIFICATION (CATERPILLAR MONITORING SYSTEM)(CATERPILLAR MONITORING SYSTEM) | 1 | |
| 1843294 | 30 SEAL | 2 | |
| 1905468 | 31 FILM-PANEL (DUAL ENGINE) | 1 | |
| 1042091 | 32 SCREW-FLAT HEAD (6-20X0.5-IN) | 4 | |
| 1071964 | 33 SCREW-PAN HEAD (6-19X0.5-IN) | 8 | |
| 4P8134 | 34 CLIP (LADDER) | 4 | |
| 7Y3173 | 35 SCREW-BUTTON HEAD (M4X0.7X12-MM) | 4 | |
| 7Y7256 | 36 SCREW-TRUSS HEAD (M4X0.7X35-MM) | 4 | |
| 9X2042 | 37 SCREW-TRUSS HEAD (M6X1X12-MM) | 12 | |
| 1963862 | 38 HARNESS AS-MONITOR | 1 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN)(CATERPILLAR MONITORING SYSTEM) | 1 |
