System And Components
154-2495 WIPER & WASHER GP-WINDOWS/N AXF1-UP
Group No: 154-2495
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 9 | |
| 5C8811 | 2 BLADE AS-WIPER (500-MM) | 2 | |
| 8T5400 | 3 CONNECTOR | 2 | |
| 8X9200 | 4 PLATE | 2 | |
| 8Y8309 | 5 ARM AS-WIPER | 2 | |
| 8T0789 | CLIP-HOSE | 2 | |
| 8T1119 | NOZZLE AS-WASHER | 1 | |
| 1028997 | 6 WIPER GP-WINDOW | 2 | |
| 1645651 | 7 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 1644598 | PLATE | 1 | |
| 1645663 | 8 COVER | 2 | |
| 1645816 | 9 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 1645817 | PLATE | 1 | |
| 2D7563 | 10 BOLT (1/4-28X1.75-IN) | 2 | |
| 2G8096 | 11 MOUNTING | 1 | |
| 5P4115 | 12 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 5S7379 | 13 BOLT (3/8-16X0.875-IN) | 4 | |
| 6V8801 | 14 NUT (3/8-16-THD) | 4 | |
| 8T4896 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 9X2044 | 16 SCREW-TRUSS HEAD (M6X1X16-MM) | 8 | |
| 1440195 | 17 HOSE |
