System And Components
194-3234 LINES GP-AIRS/N 13Z49746-UP
Group No: 194-3234
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1135346 | 1 TUBE-AIR | 1 | |
| 5H7704 | 2 SEAL-O-RING | 2 | |
| 7W1945 | 3 RETAINER | 1 | |
| 5P4479 | 4 ELBOW (FLARED-LONG) | 1 | |
| 1067633 | 5 TUBE AS-CONTROL | 1 | |
| 7M8322 | 6 CLIP | 1 | |
| 3J7352 | 7 CONNECTOR | 1 | |
| 3J7354 | 8 SEAL-O-RING | 1 | |
| 4B3388 | 9 BOLT (5/16-18X1.125-IN) | 1 | |
| 9M1974 | 10 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 2B2404 | 11 CLIP | 1 | |
| 2P0416 | 12 HOSE | 1 | |
| 3E7404 | 13 CLAMP-HOSE | 2 | |
| 0L1143 | 14 BOLT (3/8-16X2.5-IN) | 1 | |
| 5M2894 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8A8563 | 16 SPACER (8.6X20X10-MM THK) | 1 |
