4W-7005 CYLINDER HEAD GPS/N 99U8989-99999

Group No: 4W-7005
Part NumberPart NameQty
7W80711 BRACKET-FUEL PUMP1
3B19152 BOLT (3/8-16X1.375-IN)1
5M28943 WASHER-HARD (10.2X18.5X2.5-MM THK)5
0S16084 BOLT (3/8-16X3.75-IN)1
1A51835 BOLT (3/8-16X4.75-IN)2
5B26386 BOLT (3/8-16X5.25-IN)2
6N67317 SUPPORT-HOUSING (LH)1
28356668 GASKET-CYLINDER HEAD2
7W83019 FASTENER GP-CYLINDER HEAD28
1241855BOLT-12 POINT HEAD (3/4-16X7.638-IN)1
5H1504WASHER-HARD (20X33.5X5-MM THK)1
141120711 CYLINDER HEAD GP2
0L135212 BOLT (3/8-16X3.25-IN)7
8T676413 PLUG-PIPE (1/8-27-THD)2
0L135214 BOLT (3/8-16X3.25-IN)4
4N093215 PLUG-CUP (57.53-MM OD)2
5P006316 PLUG-CUP4
100692017 ADAPTER-NOZZLE8
359143918 SEAL AS-WATER32
106179219 STUD-TAPERLOCK (3/8-16X4-IN)16
7X773120 PLUG-PIPE (3/4-14-THD)2
8T676221 PLUG-PIPE (1/2-14-THD)6
4N725322 GASKET-CHAMBER8
0S159123 BOLT (3/8-16X1.5-IN)1
6N673224 SUPPORT-HOUSING (RH)1
8S919125 BOLT (3/8-16X4-IN)2
1W520726 BRACKET-FUEL PUMP1
7L477427 SEAL-O-RING8
