System And Components
136-9498 DRIVE GP-PUMPFOR USE ON THE LH SIDE OF SAE NO. 1 FLYWHEEL HOUSING, PROVIDES DRIVE FOR SAE NO. B HYDRAULIC PUMP
Group No: 136-9498
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V5101 | 1 SEAL-O-RING | 1 | |
| 7N2416 | 2 BEARING-PUMP DRIVE | 1 | |
| 1Y7574 | 3 BOLT-HEAD (3/8-16X2.5-IN) | 4 | |
| 0S1585 | 4 BOLT (1/2-13X1.5-IN) | 2 | |
| 7N2550 | 5 COUPLING | 1 | |
| 9H8872 | 6 GASKET | 1 | |
| 8P1438 | 7 COVER | 1 | |
| 0S1591 | 8 BOLT (3/8-16X1.5-IN) | 6 | |
| 7N2432 | 9 ADAPTER-HYDRAULIC PUMP | 1 | |
| 7N2533 | 10 GASKET | 1 | |
| 7N2549 | 11 GEAR-AUXILIARY DRIVE (42-TEETH) | 1 | |
| 2M0849 | 12 WASHER-HARD (13.5X25.5X5-MM THK) | 2 |
