System And Components
148-9655 PIPE GP-EXHAUSTS/N AGY1-UP
Group No: 148-9655
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B8706 | 1 KEY-WOODRUFF | 2 | |
| 1D5117 | 2 NUT-JAM (1/2-13-THD) | 2 | |
| 4B3614 | 3 SETSCREW-SQUARE HEAD | 2 | |
| 5P8026 | 4 PIN-COTTER | 1 | |
| 5T3136 | 5 LOCK | 12 | |
| 6G1071 | 6 COVER | 1 | |
| 6G1092 | 7 SPRING | 6 | |
| 6G1173 | 8 COLLAR | 1 | |
| 6G1243 | 9 PIPE | 1 | |
| 9D2724 | 10 RING-SEAL | 1 | |
| 1407782 | 11 SHAFT | 1 | |
| 1489657 | 12 BOX AS | 1 | |
| 1F0750 | 12A NUT-WELD (3/8-16-THD) | 4 | |
| 8X7422 | 12B BOSS (3/8-16X2.24-IN) | 1 | |
| 0L1351 | 13 BOLT (3/8-16X0.875-IN) | 4 | |
| 0S0175 | 14 PIN-CLEVIS | 1 | |
| 0S1566 | 15 BOLT (5/8-11X1.5-IN) | 4 | |
| 0S1588 | 16 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1590 | 17 BOLT (3/8-16X2-IN) | 6 | |
| 0S1595 | 18 BOLT (1/2-13X1.25-IN) | 4 | |
| 1U0690 | 19 SPACER (20.5X22.25X61-MM THK) | 1 | |
| 1V0019 | 20 LEVER | 1 | |
| 4L9337 | 21 BOLT (3/8-16X1.5-IN) | 1 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 5P8245 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5P8247 | 24 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 6G1504 | 25 PLATE AS | 1 | |
| 6V8801 | 26 NUT (3/8-16-THD) | 1 | |
| 8W0831 | 27 LEVER | 1 |
