160-9820 AIR COMPRESSOR GPS/N 8BR605-940

Group No: 160-9820

Part Number	Part Name	Qty
9M0379	1 BOLT	20
8N4727	2 PISTON AS-COMPRESSOR	4
1W2803	PLUG	2
7W6492	3 PLUG-PIPE (1/2-14-THD)	4
3H7311	4 GASKET-CYLINDER BLOCK	2
9M0378	5 BOLT (5/16-18X2.87-IN)	2
3B4505	6 LOCKWASHER	10
2B2695	7 BOLT (5/16-18X0.875-IN)	5
8T6764	8 PLUG-PIPE (1/8-27-THD)	2
7F2742	9 BALL BEARING	1
8T9364	10 BOLT (1/4-20X0.625-IN)	8
0S1594	11 BOLT (3/8-16X1-IN)	12
3B4506	12 LOCKWASHER	12
3H5162	13 RETAINER	1
8H9789	14 BALL BEARING	1
5M6213	15 PLUG-PIPE (1/4-18-THD)	2
2S1218	16 GASKET-CYLINDER HEAD	2
2W5189	17 CYLINDER HEAD AS	2
3F4987	17A SPRING-VALVE	2
3H5181	17B VALVE	2
9M0394	17C SEAT-VALVE	2
9M0386	17D CAP	2
9M0387	17E SEAT-VALVE SPRING	2
1W6388	17F INSERT-VALVE SPRING	2
8M7065	18 GASKET (AIR INLET)	4
0S1617	19 BOLT (5/16-18X0.75-IN)	6
2H3755	20 BOLT (5/16-18X0.43-IN)	2
6L1883	21 GASKET	1
9L2276	22 GUIDE-VALVE	4
9L2277	23 VALVE-INLET	4
9L2278	24 SPRING-VALVE	4
4N9680	25 GOVERNOR GP-AIR COMPRESSOR	1
4B1273	26 SCREW-MACHINE (10-24X0.5-IN)	3
8T4205	27 WASHER-HARD (7.2X14.5X2-MM THK)	8
8T6767	28 PLUG-PIPE (3/8-18-THD)	8
7W9827	29 ADAPTER	1
2192350	30 GASKET	1
5P4479	31 ELBOW (FLARED-LONG)	1
1170068	32 HOSE AS	1
6K1972	33 ELBOW-FLARED	1
3718029	KIT-HEAD	1
2286581	KIT-PISTON RING (AIR COMPRESSOR)
9M0402	KIT-GOVERNOR OVERHAUL (AIR COMPRESSOR)
2095258	KIT-BEARING (AIR COMPRESSOR)
2095242	KIT-ROD (AIR COMPRESSOR)
