System And Components
9Y-1595 DRIVE GP-ACCESSORY -PUMP DRIVES/N 8BR605-UP
Group No: 9Y-1595
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1V6341 | 1 SEAL | 2 | |
| 2K7471 | 2 LOCKNUT (1-14-THD) | 1 | |
| 5R7137 | 3 WASHER-SEALING | 4 | |
| 5T1009 | 4 YOKE | 1 | |
| 7N2865 | 5 GEAR-DRIVE (73-TEETH) | 1 | |
| 7N2909 | 6 GEAR AS-CLUSTER (60, 50-TEETH) | 1 | |
| 7N2910 | BUSHING | 1 | |
| 7N3005 | 7 SHAFT-IDLER | 1 | |
| 7N3006 | 8 WASHER-THRUST | 2 | |
| 2594598 | 11 SEAL-O-RING | 1 | |
| 2888960 | 12 ADAPTER AS | 1 | |
| 2A3435 | DOWEL-BEARING | 2 | |
| 8T6759 | PLUG-PIPE | 2 | |
| 3150741 | WASHER-THRUST | 1 | |
| 3151409 | BUSHING | 1 | |
| 3153096 | 13 SHAFT AS | 1 | |
| 8T2153 | SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 1095724 | SEAL AS (LIP TYPE) | 1 | |
| 3168654 | 14 CAGE AS | 1 | |
| 2A3435 | DOWEL-BEARING | 2 | |
| 1378298 | BUSHING | 1 | |
| 3150741 | WASHER-THRUST | 1 | |
| 1A1460 | 15 BOLT (1/2-13X2-IN) | 4 | |
| 1D4574 | 16 BOLT (1/2-13X6-IN) | 1 | |
| 1F7958 | 17 NUT-FULL (1/2-13-THD) | 4 | |
| 3D0472 | 18 STUD-TAPERLOCK (1/2-13X2.80-IN) | 4 | |
| 3F5792 | 19 SEAL-O-RING | 1 | |
| 3K5234 | 20 WASHER-HARD (28X49X6-MM THK) | 1 | |
| 4K0367 | 21 NUT-FULL (5/8-11-THD) | 2 | |
| 5D3954 | 22 STUD-TAPERLOCK (5/8-11X4.4-IN) | 2 | |
| 5D9514 | 23 BOLT (5/8-11X6.25-IN) | 1 | |
| 5P2546 | 24 BOLT-12 POINT HEAD (7/16-14X1.25-IN) | 12 | |
| 5P8245 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 9 | |
| 5P8247 | 26 WASHER-HARD (17X32X3.5-MM THK) | 3 |
