System And Components
230-8138 PIPE GP-EXHAUSTS/N APX365-1748
Group No: 230-8138
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5T2762 | 1 SPRING | 2 | |
| 5T3367 | 2 ELBOW | 2 | |
| 5T3369 | 3 PISTON | 2 | |
| 6G7031 | 4 ELBOW | 2 | |
| 6G7038 | 5 RING-SEAL | 2 | |
| 8W9620 | 6 TUBE AS | 1 | |
| 8W9626 | 7 BRACKET AS | 1 | |
| 8X0480 | 8 PLATE AS | 1 | |
| 8X0484 | 9 PLATE AS | 1 | |
| 9D2836 | 10 LOCK | 6 | |
| 0L1351 | 11 BOLT (3/8-16X0.875-IN) | 12 | |
| 0S1566 | 12 BOLT (5/8-11X1.5-IN) | 8 | |
| 0S1589 | 13 BOLT (5/8-11X1.75-IN) | 8 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 4 | |
| 0S1595 | 15 BOLT (1/2-13X1.25-IN) | 6 | |
| 1D5117 | 16 NUT-JAM (1/2-13-THD) | 4 | |
| 2D5238 | 17 STUD-TAPERLOCK (5/8-11X2.5-IN) | 8 | |
| 4B3586 | 18 SETSCREW (1/2-13X2-IN) | 4 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P1075 | 20 WASHER-HARD (10.2X22.5X3-MM THK) | 12 | |
| 5P8245 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5P8247 | 22 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 7K1270 | 23 WASHER (17X38X8-MM THK) | 16 | |
| 7X0448 | 24 NUT (5/8-11-THD) | 8 |
