System And Components
176-6393 LINES GP-STEERINGS/N APX1-2354
Group No: 176-6393
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G8874 | 1 CLAMP | 1 | |
| 2G8875 | 2 CLAMP | 1 | |
| 2G8895 | 3 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 1S1015 | 4 CLIP (LOOP) | 1 | |
| 6D0837 | 5 ELBOW | 1 | |
| 6E6298 | 6 VALVE GP-SOLENOID & RELIEF (STEERING) | 1 | |
| 6G8532 | 7 GUARD AS | 1 | |
| 6V0852 | 8 CAP-DUST | 1 | |
| 7I4690 | 9 PLATE AS | 1 | |
| 8D7296 | 10 JUNCTION BLOCK | 2 | |
| 8W5148 | 11 HOSE AS | 1 | |
| 8W5153 | 12 HOSE AS | 1 | |
| 8W5156 | 13 HOSE AS | 1 | |
| 8W5161 | 14 MANIFOLD | 1 | |
| 8X2701 | 15 PLATE | 2 | |
| 8X4904 | 16 HOSE AS | 2 | |
| 8X5974 | 17 MANIFOLD | 1 | |
| 8X6280 | 18 HOSE AS | 1 | |
| 1134339 | 19 SPACER (10.5X18X21-MM THK) | 2 | |
| 1509037 | 20 BAR | 1 | |
| 1518723 | 21 TUBE AS | 1 | |
| 1518725 | 22 TUBE AS | 1 | |
| 1518726 | 23 TUBE AS | 1 | |
| 1645563 | 24 UNION AS | 1 | |
| 5P9560 | UNION | 1 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 1760393 | 25 FITTING AS | 1 | |
| 8X7851 | FITTING-ORIFICE | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1766448 | 26 VALVE GP-CHECK (STEERING) | 1 | |
| 1766559 | 27 HOSE AS | 1 | |
| 3148486 | 28 HOSE AS | 1 | |
| 2977968 | 29 FITTING | 1 | |
| 2977969 | 30 CAP-DUST | 1 | |
| 3389416 | 31 HOSE AS | 1 | |
| 1488327 | 32 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488339 | 33 CONNECTOR AS | 3 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488347 | 34 ELBOW AS | 2 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488358 | 35 ELBOW AS | 1 | |
| 6V8624 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488364 | 36 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1488408 | 37 PLUG AS | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1504049 | 38 ELBOW AS | 1 | |
| 8T4149 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1518724 | 39 TUBE AS | 1 | |
| 1536237 | 40 ELBOW AS | 4 | |
| 6V9004 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645567 | 41 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1724621 | 42 ADAPTER AS | 1 | |
| 6V0301 | ADAPTER | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1760391 | 43 ADAPTER AS | 2 | |
| 8V7764 | ADAPTER-O-RING | 1 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 0L1143 | 44 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1351 | 45 BOLT (3/8-16X0.875-IN) | 5 | |
| 0S0509 | 46 BOLT (3/8-16X0.75-IN) | 2 | |
| 0S1585 | 47 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1587 | 48 BOLT (1/2-13X1.75-IN) | 10 | |
| 0S1588 | 49 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1619 | 50 BOLT (3/8-16X3-IN) | 4 | |
| 0T0055 | 51 BOLT (3/8-16X4.25-IN) | 3 | |
| 0T0065 | 52 BOLT (3/8-16X3.5-IN) | 2 | |
| 0T0573 | 53 BOLT (3/8-16X2.75-IN) | 2 | |
| 0T0772 | 54 BOLT (7/16-14X1.5-IN) | 4 | |
| 1A2029 | 55 BOLT (3/8-16X1.125-IN) | 4 | |
| 1D4707 | 56 BOLT (7/16-14X2.25-IN) | 2 | |
| 1F7958 | 57 NUT-FULL (1/2-13-THD) | 3 | |
| 1P4576 | 58 FLANGE-HALF | 12 | |
| 1P4578 | 59 FLANGE-HALF | 2 | |
| 1P4579 | 60 FLANGE-HALF | 2 | |
| 1P4582 | 61 FLANGE-HALF | 2 | |
| 2A4639 | 62 BOLT (3/8-16X1.625-IN) | 2 | |
| 3B1915 | 63 BOLT (3/8-16X1.375-IN) | 22 | |
| 3G4667 | 64 VALVE GP-RELIEF (STEERING CYLINDER CROSSOVER) | 1 | |
| 4F5192 | 65 BOLT (7/16-14X3-IN) | 2 | |
| 4J0520 | 66 SEAL-O-RING | 1 | |
| 4J0522 | 67 SEAL-O-RING | 5 | |
| 4J0524 | 68 SEAL-O-RING | 1 | |
| 4J0527 | 69 SEAL-O-RING | 2 | |
| 4J5267 | 70 SEAL-O-RING | 8 | |
| 4L9337 | 71 BOLT (3/8-16X1.5-IN) | 1 | |
| 4M2743 | 72 STUD-TAPERLOCK (3/8-16-THD) | 7 | |
| 5K9090 | 73 SEAL-O-RING | 2 | |
| 5M2894 | 74 WASHER-HARD (10.2X18.5X2.5-MM THK) | 44 | |
| 5P1075 | 75 WASHER-HARD (10.2X22.5X3-MM THK) | 14 | |
| 5P6863 | 76 CLIP (TAB) | 2 | |
| 5P6864 | 77 CLIP (SLOT) | 2 | |
| 5P7466 | 78 CLIP (SLOT) | 12 | |
| 5P7467 | 79 CLIP (TAB) | 12 | |
| 5P7468 | 80 CLIP (SLOT) | 6 | |
| 5P7469 | 81 CLIP (TAB) | 6 | |
| 5P7470 | 82 CLIP (SLOT) | 11 | |
| 5P7471 | 83 CLIP (TAB) | 11 | |
| 5P8112 | 84 GROMMET | 12 | |
| 5P8182 | 85 GROMMET (46-MM ID) | 4 | |
| 5P8244 | 86 WASHER-HARD (12X22.5X2.5-MM THK) | 8 | |
| 5P8245 | 87 WASHER-HARD (13.5X25.5X3-MM THK) | 15 | |
| 5P8444 | 88 GROMMET (37-MM ID) | 6 | |
| 1653930 | 89 BOLT (3/8-16X1.625-IN) | 1 | |
| 6V8801 | 90 NUT (3/8-16-THD) | 9 | |
| 6V9746 | 91 SEAL-O-RING | 2 | |
| 7G3832 | 92 GROMMET | 1 | |
| 7G3833 | 93 CLIP (TAB) | 1 | |
| 7G3834 | 94 CLIP (SLOT) | 1 | |
| 8M1871 | 96 STUD-TAPERLOCK (3/8-16X2.4-IN) | 2 | |
| 8W4315 | 97 HOSE AS | 2 | |
| 3148485 | 98 HOSE AS | 1 | |
| 8W5149 | 99 HOSE AS | 1 | |
| 8W5150 | 100 HOSE AS | 1 | |
| 8W5151 | 101 HOSE AS | 1 | |
| 8W5152 | 102 HOSE AS | 1 | |
| 9S8752 | 103 NUT-FULL (3/8-16-THD) | 7 | |
| 9X6458 | 104 WASHER-HARD (10.2X22.5X3-MM THK) | 12 | |
| 5S7383 | 105 BOLT (3/8-16X1.75-IN) | 2 | |
| 5S7382 | 106 BOLT (3/8-16X1.375-IN) | 2 | |
| 5P7703 | 107 GROMMET (52-MM ID) | 1 | |
| 3S8665 | 108 CLIP (LOOP) | 4 | |
| 2160245 | 109 WASHER-HARD (10.2X18.5X15-MM THK) | 1 |
