System And Components
422-9015 LINES GP-STEERINGS/N APX1-2391
Group No: 422-9015
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G8874 | 1 CLAMP | 1 | |
| 2G8875 | 2 CLAMP | 1 | |
| 2G8895 | 3 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 6D0837 | 4 ELBOW | 1 | |
| 6E6298 | 5 VALVE GP-SOLENOID & RELIEF (STEERING) | 1 | |
| 6G8532 | 6 GUARD AS | 1 | |
| 6V0852 | 7 CAP-DUST | 1 | |
| 7I4690 | 8 PLATE AS | 1 | |
| 8D7296 | 9 JUNCTION BLOCK | 2 | |
| 8W5156 | 10 HOSE AS | 1 | |
| 8W5161 | 11 MANIFOLD | 1 | |
| 8X2701 | 12 PLATE | 2 | |
| 8X4904 | 13 HOSE AS | 2 | |
| 8X5974 | 14 MANIFOLD | 1 | |
| 8X6280 | 15 HOSE AS | 1 | |
| 1134339 | 16 SPACER (10.5X18X21-MM THK) | 2 | |
| 1509037 | 17 BAR | 1 | |
| 1518723 | 18 TUBE AS | 1 | |
| 1518725 | 19 TUBE AS | 1 | |
| 1518726 | 20 TUBE AS | 1 | |
| 1645563 | 21 UNION AS | 1 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 5P9560 | UNION | 1 | |
| 1760393 | 22 FITTING AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 8X7851 | FITTING-ORIFICE | 1 | |
| 1766448 | 23 VALVE GP-CHECK (STEERING) | 1 | |
| 1766559 | 24 HOSE AS | 1 | |
| 3111877 | 25 HOSE AS | 1 | |
| 3111878 | 26 HOSE AS | 1 | |
| 3111980 | 27 HOSE AS | 1 | |
| 3111981 | 28 HOSE AS | 1 | |
| 3148485 | 29 HOSE AS | 1 | |
| 3148486 | 30 HOSE AS | 1 | |
| 3389416 | 31 HOSE AS | 1 | |
| 4231554 | 32 HOSE AS | 1 | |
| 4236691 | 33 HOSE AS | 1 | |
| 0343557 | 34 BOLT-LOCKING (3/8-16X1.125-IN) | 1 | |
| 1488327 | 35 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488339 | 36 CONNECTOR AS | 3 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488347 | 37 ELBOW AS | 4 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488358 | 38 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8624 | ELBOW | 1 | |
| 1488364 | 39 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488408 | 40 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 1504049 | 41 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T4149 | ELBOW | 1 | |
| 1518724 | 42 TUBE AS | 1 | |
| 1536237 | 43 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645567 | 44 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1724621 | 45 ADAPTER AS | 1 | |
| 6V0301 | ADAPTER | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1760391 | 46 ADAPTER AS | 2 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 8V7764 | ADAPTER-O-RING | 1 | |
| 2977968 | 47 FITTING | 1 | |
| 2977969 | 48 CAP-DUST | 1 | |
| 0L1143 | 49 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1351 | 50 BOLT (3/8-16X0.875-IN) | 5 | |
| 0S0509 | 51 BOLT (3/8-16X0.75-IN) | 2 | |
| 0S1585 | 52 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1587 | 53 BOLT (1/2-13X1.75-IN) | 10 | |
| 0S1588 | 54 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1619 | 55 BOLT (3/8-16X3-IN) | 4 | |
| 0T0055 | 56 BOLT (3/8-16X4.25-IN) | 3 | |
| 7X0291 | 57 BOLT (3/8-16X3.75-IN) | 2 | |
| 0T0573 | 58 BOLT (3/8-16X2.75-IN) | 2 | |
| 0T0772 | 59 BOLT (7/16-14X1.5-IN) | 4 | |
| 1A2029 | 60 BOLT (3/8-16X1.125-IN) | 4 | |
| 1C2251 | 61 BOLT (3/8-16X1.87-IN) | 1 | |
| 1D4707 | 62 BOLT (7/16-14X2.25-IN) | 2 | |
| 1F7958 | 63 NUT-FULL (1/2-13-THD) | 3 | |
| 1P4576 | 64 FLANGE-HALF | 12 | |
| 1P4578 | 65 FLANGE-HALF | 2 | |
| 1P4579 | 66 FLANGE-HALF | 2 | |
| 1P4582 | 67 FLANGE-HALF | 2 | |
| 1S1015 | 68 CLIP (LOOP) | 1 | |
| 1W8793 | 69 SPACER (13.8X30X20-MM THK) | 1 | |
| 2A4639 | 70 BOLT (3/8-16X1.625-IN) | 2 | |
| 3B1915 | 71 BOLT (3/8-16X1.375-IN) | 22 | |
| 3G4667 | 72 VALVE GP-RELIEF (STEERING CYLINDER CROSSOVER) | 1 | |
| 3S8665 | 73 CLIP (LOOP) | 4 | |
| 4F5192 | 74 BOLT (7/16-14X3-IN) | 2 | |
| 4J0520 | 75 SEAL-O-RING | 1 | |
| 4J0522 | 76 SEAL-O-RING | 5 | |
| 4J0524 | 77 SEAL-O-RING | 1 | |
| 4J0527 | 78 SEAL-O-RING | 2 | |
| 4J5267 | 79 SEAL-O-RING | 8 | |
| 4L9337 | 80 BOLT (3/8-16X1.5-IN) | 5 | |
| 4M2743 | 81 STUD-TAPERLOCK (3/8-16-THD) | 4 | |
| 5K9090 | 82 SEAL-O-RING | 2 | |
| 5M2894 | 83 WASHER-HARD (10.2X18.5X2.5-MM THK) | 44 | |
| 5P1075 | 84 WASHER-HARD (10.2X22.5X3-MM THK) | 22 | |
| 5P6863 | 85 CLIP (TAB) | 2 | |
| 5P6864 | 86 CLIP (SLOT) | 2 | |
| 5P7466 | 87 CLIP (SLOT) | 8 | |
| 5P7467 | 88 CLIP (TAB) | 8 | |
| 5P7468 | 89 CLIP (SLOT) | 4 | |
| 5P7469 | 90 CLIP (TAB) | 4 | |
| 5P7470 | 91 CLIP (SLOT) | 11 | |
| 5P7471 | 92 CLIP (TAB) | 11 | |
| 5P7703 | 93 GROMMET (52-MM ID) | 1 | |
| 5P8112 | 94 GROMMET | 8 | |
| 5P8182 | 95 GROMMET (46-MM ID) | 4 | |
| 5P8244 | 96 WASHER-HARD (12X22.5X2.5-MM THK) | 8 | |
| 5P8245 | 97 WASHER-HARD (13.5X25.5X3-MM THK) | 15 | |
| 5P8444 | 98 GROMMET (37-MM ID) | 4 | |
| 5S7382 | 99 BOLT (3/8-16X1.375-IN) | 2 | |
| 5S7383 | 100 BOLT (3/8-16X1.75-IN) | 2 | |
| 6V8801 | 101 NUT (3/8-16-THD) | 12 | |
| 6V9746 | 102 SEAL-O-RING | 2 | |
| 7G3832 | 103 GROMMET | 4 | |
| 7G3833 | 104 CLIP (TAB) | 4 | |
| 7G3834 | 105 CLIP (SLOT) | 4 | |
| 7G5984 | 106 CLIP (TAB) | 1 | |
| 7G5985 | 107 CLIP (SLOT) | 1 | |
| 7G5986 | 108 GROMMET | 1 | |
| 7S6719 | 109 STUD-TAPERLOCK (3/8-16-THD) | 1 | |
| 1061793 | 110 STUD-TAPERLOCK (3/8-16X2.36-IN) | 2 | |
| 8W5149 | 111 HOSE AS | 1 | |
| 8W5151 | 112 HOSE AS | 1 | |
| 9S8752 | 113 NUT-FULL (3/8-16-THD) | 5 | |
| 9X6458 | 114 WASHER-HARD (10.2X22.5X3-MM THK) | 9 |
