System And Components
125-1351 LINES GP-SCRAPER FUELPART OF 161-9102 SCRAPER AR
Group No: 125-1351
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1251211 | 1 HOSE AS | 1 | |
| 1488375 | 2 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8981 | ELBOW | 1 | |
| 1488376 | 3 ELBOW AS | 1 | |
| 6V8983 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1S0994 | 4 CLIP (LOOP) | 10 | |
| 1251213 | 5 HOSE AS | 1 | |
| 0673045 | 6 CLIP (LOOP) | 10 | |
| 6V9169 | 7 NUT (13/16-16-THD) | 2 | |
| 1251215 | 8 PLATE | 1 | |
| 4D5371 | 9 CLIP | 1 | |
| 2P1293 | 10 LOCKNUT (1-3/16-12-THD) | 2 | |
| 1488457 | 11 UNION AS (STRAIGHT) | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 1488455 | 12 UNION AS | 1 | |
| 6V8997 | UNION | 1 | |
| 6V9746 | SEAL-O-RING | 2 | |
| 1836350 | 13 SUPPORT AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 1488364 | 15 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488368 | 16 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 1251212 | 17 HOSE AS | 1 | |
| 1251214 | 18 HOSE AS | 1 | |
| 3J1907 | 19 SEAL-O-RING | 1 | |
| 3D2824 | 20 SEAL-O-RING | 1 | |
| 6V8358 | 22 VALVE-BALL (MANUAL SHUTOFF)(SCRAPER FUEL) | 1 | |
| 5P1075 | 23 WASHER-HARD (10.2X22.5X3-MM THK) | 11 | |
| 1488407 | 24 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1671795 | 25 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 8T3491 | ELBOW | 1 | |
| 5S7379 | 26 BOLT (3/8-16X0.875-IN) | 11 | |
| 1488408 | 28 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 1695863 | 29 ADAPTER AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X7945 | ADAPTER (9/16-18-THD) | 1 | |
| 6D3479 | 30 CLIP (LOOP) | 6 | |
| 8X6541 | 31 HOSE AS | 1 | |
| 2P1279 | 32 LOCKNUT (9/16-18-THD) | 1 | |
| 3F9559 | 33 LOCKWASHER | 1 | |
| 8T6907 | 34 VALVE-BALL (SCRAPER FUEL) | 1 | |
| 1488327 | 36 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 |
