System And Components
454-7490 CYLINDER GP-EJECTORBORE 209.6-MM(8.25-IN) X STROKE 1854.6-MM(73-IN)
Group No: 454-7490
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A1538 | 1 BOLT (3/4-10X2.25-IN) | 6 | |
| 9J4905 | 2 PISTON | 1 | |
| 4T9320 | 3 RING-WEAR | 1 | |
| 4547491 | 4 ROD AS | 1 | |
| 3J2700 | 4A BEARING | 1 | |
| 6E0904 | 5 CYLINDER AS | 1 | |
| 3J2700 | 5A BEARING | 1 | |
| 8J4386 | 6 SEAL-O-RING | 1 | |
| 3G3747 | 7 RING-BACKUP | 1 | |
| 4T9319 | 8 RING-WEAR | 1 | |
| 1672346 | 9 SEAL-U-CUP | 1 | |
| 2253294 | 10 SEAL-WIPER | 1 | |
| 1715908 | 11 HEAD | 1 | |
| 1A5576 | 12 BOLT (7/8-9X4.5-IN) | 2 | |
| 1743056 | 13 BOLT (7/8-9X2.5-IN) | 6 | |
| 5P8249 | 14 WASHER-HARD (24X41.5X4-MM THK) | 8 | |
| 8T1793 | 15 SEAL AS | 1 | |
| 1672228 | 16 SEAL AS-BUFFER | 1 |
