System And Components
242-1426 LINES GP-AUGER MOTORPART OF 150-1486 AUGER AR-SCRAPER
Group No: 242-1426
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4T2958 | 1 HOSE AS | 1 | |
| 1118429 | 2 VALVE GP-RELIEF | 1 | |
| 1242425 | 3 VALVE GP-FLUSHING | 1 | |
| 1251117 | 4 MANIFOLD | 1 | |
| 1320905 | 5 HOSE AS | 1 | |
| 1342286 | 6 HOSE AS | 1 | |
| 1527231 | 7 HOSE AS | 1 | |
| 1527232 | 8 HOSE AS | 1 | |
| 1527233 | 9 HOSE AS | 1 | |
| 1527235 | 10 HOSE AS | 1 | |
| 1555464 | 11 CLAMP | 2 | |
| 1555465 | 12 CLAMP | 4 | |
| 1555466 | 13 CLAMP | 2 | |
| 1555468 | 14 GROMMET | 4 | |
| 1555469 | 15 GROMMET | 4 | |
| 1555470 | 16 GROMMET | 4 | |
| 1555494 | 17 CLAMP | 2 | |
| 1555495 | 18 CLAMP | 2 | |
| 1555496 | 19 CLAMP AS | 2 | |
| 1F0748 | NUT-WELD (1/2-13-THD) | 2 | |
| 1555495 | CLAMP | 1 | |
| 2309522 | 20 TUBE AS | 1 | |
| 2309524 | 21 TUBE AS | 1 | |
| 2309525 | 22 TUBE AS | 1 | |
| 2419163 | 23 PLATE | 2 | |
| 2419164 | 24 PLATE | 2 | |
| 2419165 | 25 TUBE AS | 1 | |
| 2419166 | 26 TUBE AS | 1 | |
| 2419167 | 27 TUBE AS | 1 | |
| 2419168 | 28 BLOCK | 1 | |
| 2419169 | 29 PLATE | 2 | |
| 2419656 | 30 HOSE AS | 1 | |
| 2419657 | 31 HOSE AS | 1 | |
| 2419658 | 32 HOSE AS | 1 | |
| 2429439 | 33 HOSE AS | 1 | |
| 2429440 | 34 HOSE AS | 1 | |
| 2429441 | 35 HOSE AS | 1 | |
| 1228905 | 36 ELBOW (90-DEG) | 2 | |
| 1488312 | 37 ADAPTER AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3T4965 | ADAPTER | 1 | |
| 1488362 | 38 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8T6684 | ELBOW | 1 | |
| 1488381 | 39 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T5429 | ELBOW | 1 | |
| 1488435 | 40 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8781 | TEE | 1 | |
| 1504043 | 41 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 1620177 | 42 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 1645544 | 43 ELBOW AS | 1 | |
| 3E2333 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1645567 | 44 COUPLER AS-QUICK DISCONNECT (MALE) | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1645619 | 45 PLUG AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 1645624 | 46 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 9X2085 | ELBOW | 1 | |
| 1697394 | 47 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 8C3370 | CONNECTOR | 1 | |
| 1P3704 | 48 SEAL-RECTANGULAR | 6 | |
| 1P4577 | 49 FLANGE-HALF | 4 | |
| 1P4578 | 50 FLANGE-HALF | 12 | |
| 1P4579 | 51 FLANGE-HALF | 8 | |
| 1P5767 | 52 FLANGE-HALF | 10 | |
| 4J0522 | 53 SEAL-O-RING | 8 | |
| 4J0524 | 54 SEAL-O-RING | 2 | |
| 4L6459 | 55 BOLT (3/8-16X2.5-IN) | 3 | |
| 5H4020 | 56 COVER | 1 | |
| 5P1076 | 57 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 5P7468 | 58 CLIP (SLOT) | 7 | |
| 5P7469 | 59 CLIP (TAB) | 7 | |
| 5P7470 | 60 CLIP (SLOT) | 1 | |
| 5P7471 | 61 CLIP (TAB) | 1 | |
| 5P8182 | 62 GROMMET (46-MM ID) | 2 | |
| 5P8444 | 63 GROMMET (37-MM ID) | 3 | |
| 5S2389 | 64 BOLT-SOCKET HEAD (1/2-13X2.75-IN) | 4 | |
| 6V0852 | 65 CAP-DUST (MOTOR LINES RELIEF VALVES) | 3 | |
| 6V1572 | 66 CLIP (SLOT) | 1 | |
| 6V1573 | 67 CLIP (TAB) | 1 | |
| 6V1874 | 68 GROMMET (31-MM ID) | 1 | |
| 6V1875 | 69 GROMMET | 2 | |
| 6V8188 | 70 NUT (1/2-13-THD) | 10 | |
| 6V8398 | 71 SEAL-O-RING | 2 | |
| 6V9833 | 72 CAP (MOTOR) | 1 | |
| 7X0325 | 73 BOLT (1/2-13X2.5-IN) | 8 | |
| 7X0328 | 74 BOLT (1/2-13X3.5-IN) | 2 | |
| 7X0332 | 75 BOLT (1/2-13X4.5-IN) | 2 | |
| 7X0333 | 76 BOLT (1/2-13X4.75-IN) | 4 | |
| 8D7729 | 77 BOSS (3/8-16X0.81-IN) | 3 | |
| 8T2525 | 78 GROMMET | 1 | |
| 8T4194 | 79 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 80 WASHER-HARD (13.5X25.5X3-MM THK) | 62 | |
| 8T4835 | 81 BOLT (1/2-13X2-IN) | 2 | |
| 8T4896 | 82 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 8T5360 | 83 WASHER (12X22.5X2.5-MM THK) | 24 | |
| 8T8916 | 84 BOLT (7/16-14X1.5-IN) | 24 | |
| 8T8917 | 85 BOLT (1/2-13X1.25-IN) | 2 | |
| 8T8919 | 86 BOLT (1/2-13X1.75-IN) | 22 | |
| 8T8920 | 87 BOLT (1/2-13X3.25-IN) | 2 | |
| 9B3523 | 88 BUSHING | 1 | |
| 9B7237 | 89 BOLT (3/8-16X1.25-IN) | 9 |
