System And Components
187-6589 LINES GP-DRAFT FRAMEPART OF 191-4961 CONTROL AR-HYDRAULIC
Group No: 187-6589
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4J5140 | 1 SEAL-O-RING | 6 | |
| 8J8840 | 2 VALVE GP-CHECK (CARRY & QUICK DROP) | 2 | |
| 8T4835 | 3 BOLT (1/2-13X2-IN) | 34 | |
| 8T4223 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 127 | |
| 1P3705 | 5 SEAL-RECTANGULAR | 5 | |
| 1P4574 | 6 FLANGE-HALF | 4 | |
| 8T4224 | 7 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 6V5782 | 8 BOLT (5/16-18X1.125-IN) | 8 | |
| 1P3707 | 9 SEAL-RECTANGULAR | 10 | |
| 5T9917 | 10 PLATE AS | 1 | |
| 1P4579 | 11 FLANGE-HALF | 22 | |
| 8T8919 | 12 BOLT (1/2-13X1.75-IN) | 33 | |
| 4J0522 | 13 SEAL-O-RING | 7 | |
| 1P4578 | 14 FLANGE-HALF | 6 | |
| 8T5360 | 15 WASHER (12X22.5X2.5-MM THK) | 22 | |
| 8T8916 | 16 BOLT (7/16-14X1.5-IN) | 12 | |
| 5P8182 | 17 GROMMET (46-MM ID) | 2 | |
| 5P7470 | 18 CLIP (SLOT) | 2 | |
| 5P7471 | 19 CLIP (TAB) | 2 | |
| 6V8188 | 20 NUT (1/2-13-THD) | 13 | |
| 6V0683 | 21 GROMMET | 4 | |
| 5P7462 | 22 CLIP (SLOT) | 4 | |
| 5P7463 | 23 CLIP (TAB) | 4 | |
| 4J0524 | 24 SEAL-O-RING | 5 | |
| 2076191 | 25 BRACKET AS | 1 | |
| 1488375 | 26 ELBOW AS | 1 | |
| 6V8981 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 5S7379 | 27 BOLT (3/8-16X0.875-IN) | 8 | |
| 6V4432 | 28 BOLT (1/2-13X4-IN) | 2 | |
| 3G8935 | 29 TUBE AS | 1 | |
| 3G8939 | 30 TUBE AS | 1 | |
| 8W4705 | 31 HOSE AS | 1 | |
| 6D1641 | 32 CLIP (LOOP) | 3 | |
| 3G8054 | 33 CLIP (TAB) | 3 | |
| 3G8057 | 34 CLIP (SLOT) | 3 | |
| 8T9380 | 35 BOLT (7/16-14X1-IN) | 6 | |
| 9J2230 | 36 CLAMP | 4 | |
| 8X1810 | 37 CLAMP | 4 | |
| 9J2231 | 38 PLATE | 2 | |
| 8X1147 | 39 SPACER (10.3X15.9X74.7-MM THK) | 16 | |
| 8T4896 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 8T9378 | 41 BOLT (3/8-16X4-IN) | 6 | |
| 7X0326 | 42 BOLT (1/2-13X3-IN) | 8 | |
| 1488380 | 43 ELBOW AS | 2 | |
| 6V8988 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9169 | 44 NUT (13/16-16-THD) | 5 | |
| 9J5945 | 45 PLATE AS | 1 | |
| 2P8846 | ANGLE | 2 | |
| 5P2566 | 46 BOLT (1/2-13X1.5-IN) | 8 | |
| 1P5763 | 47 FLANGE-HALF | 16 | |
| 7X0314 | 48 BOLT (7/16-14X3-IN) | 4 | |
| 1488434 | 49 TEE AS | 3 | |
| 6V9843 | TEE | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 4T6418 | 50 PLATE | 1 | |
| 4L6454 | 51 BOLT (3/8-16X1-IN) | 4 | |
| 8W4708 | 52 HOSE AS | 2 | |
| 8W4707 | 53 HOSE AS | 2 | |
| 4T6430 | 54 HOSE AS | 1 | |
| 9J2189 | 55 TUBE AS (RH) | 1 | |
| 4T6431 | 56 HOSE AS | 1 | |
| 4T6426 | 57 TUBE AS | 1 | |
| 6V0974 | 58 GROMMET | 3 | |
| 4J9349 | 59 VALVE GP-SEQUENCE & PRESS CONT | 1 | |
| 4T6245 | 60 TUBE AS | 1 | |
| 3G8941 | 61 TUBE AS | 1 | |
| 4T6247 | 62 TUBE AS | 1 | |
| 4T6248 | 63 TUBE AS | 1 | |
| 4T6152 | 64 HOSE AS | 1 | |
| 4T6153 | 65 HOSE AS | 1 | |
| 9J2210 | 66 TUBE AS (LH) | 1 | |
| 8X6432 | 67 HOSE AS | 1 | |
| 1S1445 | 68 PLATE | 5 | |
| 8X1811 | 69 CLAMP | 10 | |
| 7X0291 | 70 BOLT (3/8-16X3.75-IN) | 10 | |
| 8W4706 | 71 HOSE AS | 1 | |
| 4T6246 | 72 TUBE AS | 1 | |
| 4T6250 | 73 TUBE AS | 1 | |
| 4T6249 | 74 TUBE AS | 1 | |
| 4T6251 | 75 TUBE AS | 1 | |
| 8J5294 | 76 TUBE AS | 1 | |
| 8S8948 | 77 HOSE AS | 1 | |
| 8S8942 | 78 HOSE AS | 1 | |
| 9J2193 | 79 TUBE AS | 1 | |
| 2167764 | 80 TUBE AS | 1 | |
| 1U1414 | 81 BLOCK | 1 | |
| 5P4295 | 83 CLIP | 4 | |
| 1U1410 | 84 CLAMP | 2 | |
| 5P2228 | 85 BOLT (1/2-13X1-IN) | 8 | |
| 1P3706 | 86 SEAL-RECTANGULAR | 2 | |
| 7X0333 | 87 BOLT (1/2-13X4.75-IN) | 8 | |
| 5P2424 | 88 BOLT (1/2-13X2.25-IN) | 12 | |
| 7X0336 | 89 BOLT (1/2-13X5.5-IN) | 2 | |
| 1853365 | 90 UNION AS | 2 | |
| 8T0129 | UNION | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1864762 | 91 ELBOW AS | 1 | |
| 6V9351 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 5P1075 | 92 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 5P1076 | 93 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 1847427 | 94 HOSE AS | 1 | |
| 1847426 | 95 HOSE AS | 1 | |
| 5K1094 | 96 LOCKWASHER | 2 | |
| 6D4636 | 97 CLIP (LOOP) | 6 | |
| 7X0618 | 98 WASHER-HARD (13.5X40X5-MM THK) | 2 | |
| 9X0941 | 99 LOCKNUT (1/2-13-THD) | 8 | |
| 7X0328 | 100 BOLT (1/2-13X3.5-IN) | 4 |
