System And Components
4T-1838 EJECTOR GPPART OF 161-9098 CHASSIS AR
Group No: 4T-1838
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1447289 | 1 ROLLER GP-EJECTOR GUIDE | 2 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 4J9878 | 3 PIN | 2 | |
| 8T8925 | 4 BOLT (3/4-10X4.75-IN) | 2 | |
| 2436940 | 5 EJECTOR AS | 1 | |
| 6J1399 | 5A BRACKET | 1 | |
| 6V8182 | 6 NUT (3/4-10-THD) | 4 | |
| 1447314 | 7 ROLLER GP-EJECTOR | 2 | |
| 5F0585 | 7A CONE-BEARING (TAPERED ROLLER) | 1 | |
| 1447315 | ROLLER AS | 1 | |
| 3J4777 | 7B SEAL-LIP TYPE | 1 | |
| 5F0585 | 7C CONE-BEARING (TAPERED ROLLER) | 1 | |
| 5F0589 | CUP-BEARING (TAPERED ROLLER) | 2 | |
| 8T4896 | 7D WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5S7379 | BOLT (3/8-16X0.875-IN) | 4 | |
| 1447316 | 7E GASKET | 1 | |
| 0312523 | 7F BOLT-LOCKING (7/16-14X1.25-IN) | 2 | |
| 8W4560 | 7G RETAINER | 1 | |
| 1447317 | 7H COVER | 1 | |
| 8W4569 | 7J SHAFT AS | 1 | |
| 7X0375 | 8 BOLT (3/4-10X5-IN) | 2 | |
| 1447318 | 9 ROLLER GP-EJECTOR | 2 | |
| 1B3978 | 9A CUP-BEARING (TAPERED ROLLER) | 1 | |
| 1447319 | ROLLER AS | 1 | |
| 5P5588 | 9B SEAL-LIP TYPE | 1 | |
| 1B3980 | 9C CONE-BEARING (TAPERED ROLLER) | 1 | |
| 1B3978 | CUP-BEARING (TAPERED ROLLER) | 2 | |
| 0312523 | 9D BOLT-LOCKING (7/16-14X1.25-IN) | 3 | |
| 1447320 | 9E COVER | 1 | |
| 1U4242 | 9F RETAINER | 1 | |
| 8T4896 | 9G WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5S7379 | BOLT (3/8-16X0.875-IN) | 4 | |
| 1447295 | 9H GASKET | 1 | |
| 8W2032 | 9J SHAFT AS | 1 | |
| 7X0391 | 10 BOLT (7/8-9X5.5-IN) | 2 | |
| 7X0449 | 11 NUT-FULL (7/8-9-THD) | 2 | |
| 4T2350 | 12 RETAINER | 4 | |
| 8T8917 | 14 BOLT (1/2-13X1.25-IN) | 8 |
