179-4301 TANK GP-HYDRAULICS/N AXT1-UP

Group No: 179-4301

Part Number	Part Name	Qty
0T0883	1 WASHER (0.531X1X0.065-IN THK)	1
1J8595	2 GASKET	1
2G9354	3 COVER AS	1
5D4218	BLOCK	1
2G9356	4 GASKET	1
3D6678	5 STRAINER (METAL)(HYDRAULIC TANK)	1
3G7233	6 FILTER GP-OIL (HYDRAULIC)	1
4D6082	7 BOLT (1/2-13X1.5-IN)	1
4J3754	8 CAP-FILLER (HYDRAULIC TANK)	1
4J3816	9 PLATE	1
5D1901	10 WASHER (106.5X126.5X2.5-MM THK)	1
5P1296	11 HOSE
5T0096	12 SCREEN AS (HYDRAULIC TANK)	1
5T4617	13 COVER AS	1
1F0750	NUT-WELD (3/8-16-THD)	4
6C3680	RIVET-POP	8
5T4624	14 MOUNTING	1
6G1249	15 GASKET	1
6G9765	16 TUBE AS	1
6G9988	17 ELBOW	1
6J1080	18 GROMMET	1
6J1081	19 GLASS-SIGHT	1
6J1126	20 PLATE-INDICATOR	1
7B2805	21 RING-LOCK	1
2G9034	22 COVER	1
8L8137	23 CLIP	1
1925125	25 ELBOW	1
1263584	26 TUBE AS	1
0307335	27 BOLT-LOCKING (5/8-11X1.5-IN)	4
0310219	28 BOLT-LOCKING (3/8-16X1.75-IN)	8
0352017	29 SCREW-BUTTON HEAD (3/8-16X1-IN)	4
0L2070	30 BOLT (3/8-16X2.25-IN)	1
0S1594	31 BOLT (3/8-16X1-IN)	76
1794302	32 TANK AS	1
1L5072	33 DOWEL	1
2H6338	35 SEAL-O-RING	3
2K4973	36 LOCKNUT (3/8-16-THD)	77
3B4610	38 PIN-COTTER	1
4J3815	39 GASKET	1
4P0519	40 ADAPTER AS-DRAIN	1
1095839	PLUG-DRAIN (HYDRAULIC TANK)	1
5D0353	41 BOLT-LOCKING (3/8-16X1-IN)	4
5D1902	42 COVER-HYDRAULIC CAP	1
5H6005	43 SEAL-O-RING	4
5H8985	44 PIN-SPRING	1
5K7143	45 BOLT-SELF-LOCKING (1/2-13X1.5-IN)	8
5K9107	46 BOLT-LOCKING (3/8-16X0.75-IN)	1
5M2894	47 WASHER-HARD (10.2X18.5X2.5-MM THK)	13
5P1717	48 CLAMP-HOSE	4
5P8245	49 WASHER-HARD (13.5X25.5X3-MM THK)	10
5P8247	50 WASHER-HARD (17X32X3.5-MM THK)	4
6N8863	51 WASHER (10.2X32X2.5-MM THK)	3
6V3830	52 SEAL-O-RING	1
7F8268	53 SEAL-O-RING	1
8T2275	54 BALL	1
9M7394	55 LEVER (HYDRAULIC TANK)	1
9S1366	56 BOLT (1/2-13X2.5-IN)	2
