System And Components
3N-9118 SHUTOFF GP-AIR24/32-VOLT
Group No: 3N-9118
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 2 | |
| 5S1188 | 2 SEAL-O-RING | 2 | |
| 3N7848 | 3 SPRING | 1 | |
| 1W9070 | 4 DIODE AS | 1 | |
| 1H3337 | 5 BOLT (1/4-20X0.875-IN) | 2 | |
| 2458342 | 6 GASKET | 1 | |
| 1354649 | 7 SPRING | 1 | |
| 5N5129 | 8 SHAFT | 1 | |
| 5N1703 | 9 SPACER (6.8X21X9.52-MM THK) | 1 | |
| 3N9117 | 10 ELBOW | 1 | |
| 5N3160 | 11 STUD (1/4-20X2-IN) | 1 | |
| 1806363 | 12 LATCH | 1 | |
| 6V8185 | 13 NUT (1/4-20-THD) | 1 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5H1190 | 15 SEAL-LIP TYPE | 1 | |
| 4N2883 | 16 SHAFT-SHUTOFF | 1 | |
| 2L3605 | 16A PIN-SPRING | 1 | |
| 5N2829 | 16B BUSHING-TERMINAL | 1 | |
| 4P8021 | 17 VALVE AS (AIR SHUTOFF) | 1 | |
| 1C0569 | 18 BOLT (5/16-18X0.5-IN) | 2 | |
| 9M1974 | 19 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1806364 | 20 BRACKET AS | 1 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5N3852 | 22 BEARING | 2 | |
| 4N3890 | 23 SOLENOID AS (24-VOLT)(AIR SHUTOFF) | 1 | |
| 6V8362 | SCREW-MACHINE (8-32X0.31-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 5N5131 | 25 BLOCK AS | 1 | |
| 5H5744 | 26 BUSHING-TERMINAL | 1 |
