System And Components
193-7829 LINES GP-AFTERCOOLER AIRS/N BCP1-UP
Group No: 193-7829
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4985 | 1 CLAMP-HOSE | 2 | |
| 1770581 | 2 HOSE | 3 | |
| 1783844 | 3 HOSE | 1 | |
| 1939879 | 4 TUBE | 1 | |
| 1974581 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 2180607 | 6 TUBE | 1 | |
| 2180608 | 7 HOSE | 1 | |
| 2180609 | 8 BRACKET AS | 1 | |
| 1707491 | STUD-WELD (M10X1.5X35-MM) | 2 | |
| 2268360 | 9 TUBE | 1 | |
| 1440367 | 10 CLAMP-HOSE | 18 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 3 | |
| 8T4139 | 13 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4179 | 14 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4195 | 15 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 9X2646 | 17 CLIP (SLOT) | 3 | |
| 9X2647 | 18 CLIP (TAB) | 3 |
