System And Components
220-7075 DRIVE GP-FANS/N CEZ1-474
Group No: 220-7075
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1L8545 | 1 SPACER (1X1.25X0.99-IN THK) | 1 | |
| 5M9735 | 2 SEAL-LIP TYPE | 1 | |
| 6B1124 | 3 BALL BEARING | 2 | |
| 7C2164 | 4 BLOCK | 1 | |
| 7C8370 | 5 CAP-DUST | 1 | |
| 9L3474 | 6 V-BELT SET (INCLUDES 3-BELTS)(FAN DRIVE) | 1 | |
| 1303216 | 7 V-BELT SET (INCLUDES 2-BELTS)(FAN DRIVE) | 1 | |
| 1850838 | 8 ROD-ADJUSTMENT | 1 | |
| 1949463 | 9 DRIVE GP-FAN | 1 | |
| 2093672 | 10 PULLEY | 1 | |
| 2153296 | 11 ARM AS | 1 | |
| 3E4999 | PIN-SPRING | 1 | |
| 2207076 | 12 ADAPTER-FAN | 1 | |
| 2229151 | 13 WASHER-HARD (11X32X5-MM THK) | 1 | |
| 2244924 | 14 PULLEY-FAN | 1 | |
| 2244925 | 15 PULLEY | 1 | |
| 5P1076 | 16 WASHER-HARD (13.5X30X4-MM THK) | 1 | |
| 6V4248 | 17 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4183 | 19 BOLT (M12X1.75X40-MM) | 5 | |
| 8T4186 | 20 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4196 | 21 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4244 | 23 NUT (M12X1.75-THD) | 2 | |
| 8T4910 | 24 BOLT (M12X1.75X60-MM) | 1 | |
| 8T5005 | 25 BOLT (M10X1.5X70-MM) | 6 | |
| 8T6868 | 26 BOLT (M12X1.75X80-MM) | 1 | |
| 9F4446 | 27 SEAL-O-RING | 1 |
